Hi-accuracy 0.1% Handheld Lcr Meter Lcrzdq ? Esr Tester 10khz Usb 822a

US $173.00

Shenzhen, China
Jun 9th

Open on mobile:
QR code

Note: we'll ship this item via Epacket to US, usually the delivery time is about 3 weeks; For other countries, we'll ship it via registered air mail of Post, usually the delivery time is about 40-50 days. If you want express mail service, please contact us for extra postage in advance. Features: ? Basic measurement accuracy: 0.1% ? Test signal frequency up to 10kHz (100Hz, 120Hz, 1KHz, 10KHz) ? Measurement speed up to 10meas/sec ? Large character display with bright white backlight ? Ultra-low power consumption, battery-powered for 24 hours of continuous used ? Automatic identification function (Ai) ? Constant output impedance: 100 Ohm ? Percentage display and 4-tolerance comparator: 1%, 5%,10% and 20% ? Automatic Open/Short correction detection ? Data hold, Max/Min/Average recording ? Utility function configuration and current setup recovery after power-off ? Standard Mini-Usb interface, SCPI compatible Accessories: 7.2V NI-MH rechargeable battery, AC adapter, Short-circuit plate, 4-terminal Kelvin test leads, SMD 4-terminla Kelvin test Tweezers(optional), PDF manual. Specifications: Function Measurement Parameters Primary Parameters: L / C / R / Z Second Parameters: D / Q / ? / ESR Equivalent Circuits Serial, Parallel Auto LCR Function Manual/Auto Ranging Mode Auto Test Terminals 2-terminal, 4-terminal,5-terminal Measurement Speed 10meas/sec(Fast), 5meas/sec(Medium), 2meas/sec(Slow) Correction Short, Open Tolerance Mode 1%, 5%, 10%, 20% Input protection fuse 0.1A / 250V Interface Mini-USB(virtual serial port) Test Signal Signal Frequency 100Hz, 120Hz, 1kHz, 10kHz Test Signal Level 0.6Vrms Output Impedance 100 ? Display Display LCD primary-secondary dual display Backlight Battery supply: when backlight is on, luminance is reduced by half 15s later and automatically turned off 30s later Powered by adapter: backlight is on until manually turned off Readings Max. counts of primary parameter: 40,000; D / Q / ? Min. resolution of Secondary parameter:0.0001 Basic Accuracy 0.1% Measurement Display Range L 0.001uH --- 1000.0 H C 0.001pF --- 20.000mF R/Z 0.0001W --- 10.000MW ESR 0.0000W -- 999.9W, resolution: 0.0001W D 0.0000 -- 9.999, resolution: 0.0001 Q 0.0000 – 9999, resolution: 0.0001 ? -179.9° -- 179.9°, resolution: 0.01° Power Supply Battery Model 7.2V Ni-MH 600mAH rechargeable battery AC Adapter Input: 220V(1±10%) or 110V ;Output: 9V DC Operating Current Max.: 28 mA, Typical: 25mA (1kHz ,100? load) Standby(Power off) Current Max.: 2uA Battery Life 24 hours (Typical), based on backlight off and new fully charged Ni-MH battery Charge Time and Current Continuous charge time: Max. 80min Charging current: Max. 150mA Auto Power Off 5min, 15min, 30min, 60min, OFF available Battery Capacity indicate Real-time display on LCD General Operation Condition Temperature 0°C -- 40°C Relative Humidity

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	u822a
Country of Manufacture	China
MPN	u822a
Brand	generic
Country/Region of Manufacture	China
UPC	Does not apply
