Hiee Rm5833 5.8g 7'' Lcd Diversity Ground Station Monitor With Reciever Fpv

US $144.26

Shenzhen, China
Jun 9th

Open on mobile:
QR code

HIEE RM5833 5.8G 7'' LCD Diversity Ground Station Monitor with Reciever for FPV Description: HIEE RM5833 5.8G 7'' LCD Diversity Ground Station Monitor with Reciever for FPV Specifications: 1.Screen size: 7" 2.Screen style: TFT LCD screen 3.Physical resolution: 800 x 480 4.Brightness: 400-450cd/m^2 5.Contrast: 500:1 6.Visual angle: 70°/70° 50°/70°(Level/Vertical) 7.Working voltage: DC 2S-6S(Circular plug,inner positive &outside negative) 8. input power:7.2W(DC 12V) 9.Dimension: 178mm x 118mm x 25mm 10. 5.8G diversity feature, the stronger wireless signal first 11.Support output for two 5.8G RF AV OUT, one input for AV IN 12.Support 10 languages menu selection 13.Working temperature: -10°C~+ 65 °C 14.Operation of key-press 1)The RF key is used to adjust the frequency group (A.B.E.F) 2)The SCAN key for automatic scanning channel . 3)The CH key is to adjust channels from CH1 to CH8 4)Press the+ - key to adjust the brightness. 5)Press key 3 seconds to switch it on, press again to power off. 6)MENU key: press MENU button to enter the menu , then press the MENU key to select the menu items, following press the + -button to adjust the menu items' coefficient 15. Three methods to exit menu : 1)Long press MENU key to exit the menu for 3-4 seconds . 2)Without doing anything for 5 seconds to exit the menu automatically . 3)Select the exiting item for the menu,and then press the + - key to exit it 16.Frequency table by reference: 17.The right of the LED light is on when charging,correspondingly out when charging fully. 18. The blue LED light on the left side represents RF1,the red for RF2. Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail( no tracking number for items under $65), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.
