High-accuracy Kelvin(4-wires) Small Low Resistance Milliohm Meter Multimeter5302

US $142.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

DT-5302 DMM with Kelvin(4-wires) small resistance measurement is for high accuracy, high resolution portable Milliohm Meter or field use. Features: 1.Four terminal Kelvin measurement 2.4000 counts digital LCD display with backlit 3.high resolution to 0.1m? with test current to 200mA 4.Relative Zero & Data Hold 5.overload protection on all ranges 6.low battery indication 7.MAX/MIN recording mode 8.Diode check & Continuity Test Low resistance Range :400m?,4?,40? Resolution :0.1m?,1m?,0.01? accuracy:±(1.0%+10d),±(1.0%+5d),±(1.0%+5d) current:200Ma,20 mA,2 mA OHMS Range :400?,4K?,40K?,400K?,4M?,40M? Resolution :0.1?,1?,10?,100?,1K?,10K? Accuracy :±(1.0%+4d),±(1.5%+2d),±(2.5%+3d),±(3.5%+5d) Current Range :400?A,4000?A,40mA,400 mA Resolution :0.1?A,1?A,0.01mA,0.1mA Accuracy :±(1.5%+5d) DC Voltage Range :400mV,4V,40V,400V,1000V Resolution :0.1mV,1mV,0.01V,0.1V,1V Accuracy :±(1.0%+5d),±(1.2%+5d) AC Voltage Range :400mV,4V,40V,400V,1000V Resolution:0.1mV,1mV,0.01V,0.1V,1V Accuracy:±(1.2%+10d),±(1.5%+10d) Capacitance Range :4nF,40 nF,400 nF,4uF,40 uF,400 uF,4mF,40mF Resolution :1pF,10 pF,0.1 nF,1 nF,10 nF,0.1 uF,1 uF,10 uF Accuracy :±( 5%+0.05nF), ±(5.0%+20d),±(3.0%+10d),±(4.0%+10d),±(10%+10d) Specifications: Range Resolution Accuracy Low resistance 400m? 0.1m? ±(1.0%+10d) 4? 1m? ±(1.0%+5d) 40? 0.01? ±(1.0%+5d) OHMS 400? 0.1? ±(1.0%+4d) 4K? 1? ±(1.5%+2d) 40K? 10? 400K? 100? 4M? 1K? ±(2.5%+3d) 40M? 10K? ±(3.5%+5d) Current 400?A 0.1?A ±(1.5%+5d) 4000?A 1?A 40mA 0.01mA 400mA 0.1mA DC Voltage 400mV 0.1mV ±(1.0%+5d) 4V 1mV 40V 0.01V 400V 0.1V 1000V 1V ±(1.2%+5d) AC Voltage 400mV 0.1mV ±(1.2%+10d) 4V 1mV 40V 0.01V 400V 0.1V 1000V 1V ±(1.5%+10d) Capacitance 4nF 1pF ±(5.0%+0.05nF) 40nF 10pF ±(5.0%+20d) 400nF 0.1nF ±(3.0%+10d) 4uF 1nF 40uF 10nF 400uF 0.1uF ±(4.0%+10d) 4mF 1uF ±(10%+10d) 40mF 10uF Unspecified Size (HxWxD): 200x92x50mm Weight: 700g Accessory: 4-wire Test leads, “AAA” x6 batteries, Gift box with Carrying case. Note: we'll ship this item via Epacket to US, usually the delivery time is about 2-3 weeks; for other countries, we'll ship it via registered air mail of China Post, usually the delivery time is about 40-50 days. If you want express mail service, please contact us for extra postage in advance.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	DT-5302
Country of Manufacture	China
MPN	DT-5302
Country/Region of Manufacture	China
