High Pass Filter (LTCC Construction) HPF9700M Pass Band 9.7G - 17 GHz, US $59.95 – Picture 0
High Pass Filter (LTCC Construction) HPF9700M Pass Band 9.7G - 17 GHz, US $59.95 – Picture 0

High Pass Filter (ltcc Construction) Hpf9700m Pass Band 9.7g - 17 Ghz

US $59.95

  • Weston, Massachusetts, United States
  • May 24th
Open on mobile:
QR code
Part Number: HPF9700M -- High Pass Filter (LTCC Construction) Pass Band 9,7G-16.98 GHz. SKU#: AK28-014C. Enclosure uses RF Design Kit with dimension 0.9375"x0.75x0.48". S-Parameter of part measured on VNA (8 GHz to 17 GHz) is shown in third picture. Made in USA. Features Operational Temperature: -55 ~ 100 Temperature Stable 3dB Cut Off Frequency: 9070 MHz RF Power Input: 7W max. at 25 Insertion Loss in Pass Band: (1.5dB Max) High Quality SMA Female Connector High Quality Rogers RO4350 RF PCB ROHS Compliant Applications Harmonic Rejection Transmitters / Receivers / SDR Test Instrumentation Resources (PDF Datasheet) https://cdn.shopify.com/s/files/1/1592/7469/files/HPF9700M.pdf
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Country/Region of Manufacture United States
Brand LOTUS
Filter Type High Pass
High Pass Frequency 9.7~17GHz
MPN HPF9700M
