High Precision Cnc Router Machine 4th Axis 3-jaw 100mm Chuck Rotary Axis 100:1

US $350.00

TX, United States
Sep 1st

Open on mobile:
QR code

USA Stock & Free VAT & Fast Shipping High Precision CNC Router Machine 4th Axis 3-Jaw 100mm Chuck Rotary Axis 100:1 with 65mm tailstock for CNC Router Engraving Milling Machine Good News: We have USA Warehouse in USA,so we will ship this product from USA to you Fast shipping time,no Taxes and no VAT to you. Package include: 1Set 4th axis K11-100mm Gapless harmonic reducing ratio 100:1 (assembled with nema23 stepper motor and 3 jaw chuck) 1Pcs 65mm Tailstock 1Set of Anti-claw 1. Engraving machine fourth axis (A axis, Rotational Axis, CNC dividing head) gapless harmonic reducer Engraving Machine 4th Axis gapless harmonic reducer gearbox Chuck type: K11-100mm three jaw centering chuck Center height: 65mm Total height: 115mm Angle: 0.036°/ step Gear box output shaft diameter: 25mm Reducing ratio: ( 100:1 ) Weight: 6.5KG 3 jaw chuck: Suitable for clamping various types of materials. The fourth axis parameter settings: Mach3 system settings: the pulses required for 1° (Motor 1 lap pulses x Driver fine fraction x Reduction ratio) 360° For example: 57mm 2- phase stepper motor, fine fraction of 16, reduction ratio 100:1 (200 x 16 x 100) / 360=888.88888888) Weihong system settings: 1 pulse along the angle 360°/(Motor 1 lap pulses x Driver fine fraction x Reduction ratio) For example: 57mm 2- phase stepper motor, fine fraction of 16, reduction ratio 100:1 360 / (200 x 16 x 100) =0.001125 65mm tailstock Center Height: 65mm Stretch distance: 50mm Top tip: Activity type Axial locking wrench for tailstock X or Y axis instead of the algorithm is: Circumference (the motor 1 Circle of pulse numberr the drive of subdivision number reduction ratio) Engraving different sizes of round bars, equivalent needs to be set. Nema23 Stepper Motor Step Angle: 1.8 deg. Holding Torque: 1.2Nm Phase Resistance: 1ohms Current:3A Inductance:2.8mH+/-20% Frame Size: 57x57x56 mm Body Length: 56mm Lead: Red: A+,Green: A-,Yellow: B+, Blue: B- 65mm Tailstock Center Height: 65mm Stretch distance: 50mm Top tip: Activity type Axial locking wrench for tailstock Nema23 57mm 3A 2-phase 4 wire Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately Items will be shipped within 1-2 days upon the receipt of payment. Payment We accept paypal payment, all Paypal must be confirmed(shipping and billing address must match and correct and it need tell us your telephone no for delivery) Problem&Feedback Please give us the opportunity to resolve any problem when you have, we concern your problem and we will try our best to resolve it. We are a new member in ebay now, and need understand both of sides Pls email us before you want to leave any negative feedback Refund When you have the parcel, and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos Any reason required for all refund. Item must be in it's original condition and no physical damage. Buyer responsible for all shipping cost Contact us Welcome worldwide customer inquire and questions, we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Center height	65MM
Number of Jaws	3
Country/Region of Manufacture	China
Stepper motor	Nema23 57mm 3A 2-phase 4 wire
Total height	115mm
Country//Region of Manufacture	China
Chuck	K11-100mm 3 jaw centering chuck
Reducing ratio	100:1
Model	K11-100MM
MPN	Does not apply
Angle	0.018°/ step (0.036°/ step for 50:1)
Brand	RATTM MOTOR
Accessories	Set of Anti-claw and wrenc
UPC	Does not apply
