High Voltage Phasing Stick Pc11k 11kv

US $3600

Concord, New Hampshire, United States
Nov 10th

Open on mobile:
QR code

High Voltage Phasing Stick. Model PC11K. 0-11kV measuring range. The NEW PC range of Multifunction Phasing Sticks utilizes a long established technique to detect and measure High Voltages and perform phasing tests. These Dual Poles instruments incorporates modern, high quality glass fiber front end, composite polyurethane. main body molding to give tough and very light weight construction. They are not just VDE0681 part 5 compliant and IEC1243-2. They are practical and efficient. Because of their multifunction capabilities, you do not need to buy separates instruments, You can therefore stay within your budget without compromise. They are supplied complete with instruction manual and two FACTORY test report certificates and, optionally, a calibration, a calibration certificate. They are housed in a superb high quality modern plastic case with shock absorbing foam. The NEW PS range is self powered and does not require batteries. They are suitable for indoor and outdoor use (in dry weather). They do not require dismantling or re-assembling and do not have any user assembled parts, so eliminating the ricks of assembly mistake and accidents during high voltage work in a breakdown situation. The PC11K does not have any dangerous, user selectable/assembled metal parts exposed to high voltage, thus, the user can't be exposed to lethal voltage while handling or testing with the new PC11k. They are over-designed for increased user protection and are lighter than any other sticks on the market today. The indicator has been screened for high immunity to interference fields. They determine the voltage and positively identify phases up to 11kV. Other measuring ranges available from 6.6kV up to 44kV systems. Higher voltages can be manufactured upon request. Fiberglass is of hot stick quality and tested to IEC specs (100kv / 300mm for 1 min) all front end (resistors) are encapsulated. These analog phasing sticks are ideally suited for testing of grounded or ungrounded systems. Important applications include checking voltage fuses, testing for correct phase connections and for absence of high voltage on de-energized lines or apparatus. The duals scale read direct (no multiplier) in kV AC or in % of full scale and is color coded (green = in phase Red = out of phase) A bright neon is included on the scale for easy visibility indoor and it has dual purpose. The neon is also a detector and start to light when the voltage across the poles is higher than 1200VAC. In case of unlikely failure of the analog scale indicator, the neon can be used as voltage detector. Our manufacturing process and method ensure that every product is not just fully functional and calibrated after the assembly lines, but also within tight specification tolerances before leaving the strict quality control of the factory. They are then re-checked, re-calibrated and certified by an independent recognized authority. All our phasing sticks are versatile and single range for added safety. They have low metal content and nylon is used wherever possible. They are equipped with two fixed length poles connected by a strong flexible, insulated cable. Hand guards are standard on all models. They are easy to handle, light weight, well insulated and designed to ensure maximum operator safety. Keywords: Phasing Stick, High Voltage, Meter, Fiberglass Insulated, Transmission Lineman, High Voltage Safety.
