Hipotronics 800pl 880pl - 10ma Dc Hipot Tester 115v Supply

US $3,300.00

Houston, Texas, United States
Apr 22nd

Open on mobile:
QR code

The Hiptoronics 880PL-10mA DC hipot tester is an economical solution to DC field testing of cables, terminations, motors, generators and other electrical apparatus. The Hipotronics 880PL10-MA 80kV and is self-contained in a single, rugged and durable enclosure, which is complete from input line cord to high voltage output cable. Cable storage space is conveniently located inside. The 880PL testers features accurate kV meter readings regardless of load current. Accurate voltage and current measurements are assured via voltage readings that are taken directly at the output of the high voltage transformer and current measurements are taken in the return leg. Safe discharging of both the test object and the high voltage transformer occur whenever the high voltage is turned off. Output power is provided by means of a full-wave voltage doubling rectifier circuit with silicon rectifiers. Features of the Hipotronics 880PL-10MA include: Rugged, portable single-piece construction Shielded output cable Full-wave voltage doubling rectifier circuit Zero start interlock and guard circuit Internal discharge solenoid Meter accuracy ± 2% full scale 10 mA current rating for cable charging External interlock provisions Three range voltmeter Four range current meter No internal leakage at full load Instantaneous overload relay Surge-limiting resistors in HV output Benefits of the Hipotronics 880PL include: Ideal for field testing – compact, lightweight and rugged makes it suitable for field orientated applications Operator Safety – the power supply and test object are automatically grounded when high voltage is turned off and there is no exposed high voltage Simple to Use - a minimal amount of setup time and a simple control panel allows simple testing every time Accurate Leakage Current Measurement - while guard circuit eliminates stray leakage currents Technical Specifications for the Hipotronics 880PL-10MA: Input Voltage: 120V, 50/60 Hz Output Voltage: 0-80 KV Output Current: 10 mA Polarity: Negative Output, Possitive Ground Metering: + 2% full scale accuracy Ripple: 0.5% per mA with rated resistance

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...

Brand

HIPOTRONICS
