Hirox Mx-bgaz 3d Rotating Hi-scope Lens Bga Solder Inspection Kh/bh Microscope

US $488.00

Saint Paul, Minnesota, United States
Jan 30th

Open on mobile:
QR code

Hirox MX-BGAZ 3D Rotating Lens For BGA Inspection Lens came with a Hirox KH-1000 Hi-Scope 3D Inspection Microscope that we currently have for sale. It includes one adjustable arm with light pen/brush. Includes original box and looks like it's in absolutely beautiful condition. Copied from here: http://caltexsci.com/bga_lens.htm Precision made BGA lens from Hirox Optics, BH-1000 BGA Scope system offers easy-to-use, lower-ownership-cost, and superior optical images quality than X-Ray system and other microscopes for inspecting BGA packaging, Micro BGA, solder joint, and lead coplanarity. Optical System of BH-1000 system (MX-BGAZ) Magnification Range: 50x - 200x (Field of view 5.1 mm - 1.5 mm) Magnification changed by adjusting Working Distance Built-in Straight down view 50x-200x for solder joints, pad, trace, through holes, and solder paste. BGA prism tip offer super 90 degree angle with 0.025 mm stand off height from surface of PCB. User replaceable BGA Prism tip: Specially designed prism held by soft spring to prevent costly damage to lens (just like a shock absorber), and the prism is easily replaceable by user in 10 seconds, to avoid down time and costly repair. 3-D BGA Lens design with Optical Rotation to offer 3-D rotational viewing of BGA balls and Pads inside BGA package, so you can see top and bottom BGA ball interfaces better than any other systems. Dual Articulated Fiber Optic Lighting with various brush fiber tips for side lighting and back lighting. With integrated Flexible and Fully Adjustable Fiber Optic Lighting, the system offers brighter lighting to view BGA balls INSIDE tight BGA package. MX-BGAZ lens allows to go in between 1.0 mm (0.04 inch) component gaps of those high density boards, with integrated lighting, Aperture control and fine focus. Close point focusing, high resolution (12 lens elements) design. Interchangeable with other Hi-Scope 2-D or 3-D lenses for expandability. So now with one BGA Scope system you can have Macro View (1x-20x) for the whole board, 3D Scope (50x-300x) for SMT inspection, BGA Scope lens (50x-200x) for BGA package, Laser Light adapter (50x-300x) for Solder Paste height measurement.. Terms of Sale Buyer pays $12 shipping (continental US). HI, AK, PR and Canada pay $22. Paypal usually ships within 24 hours. International bidders (non-Canadian) PLEASE contact us before bidding. Thanks for your interest. Please email with any questions.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Hirox
MPN	MX-BGAZ
Model	3D Optical Rotating Lens
Country/Region of Manufacture	United States
