Hitachi Sj200-075hfu2,variable Frequency Drive, 10 Hp, 460 Vac, 3 Phase Input

US $559.00

Dallas, Texas, United States
Jan 29th

Open on mobile:
QR code

SquareTrade © AP6.0 Input: 380~480VAC, Three Phase Output: 10 HP, 380~ 480VAC, 3 Phase 7.5kW, 13.3kVA, 16A HITACHI MODEL SJ200-075HFU2 12 Months WARRANTY Brochure Reference Guide Instruction Manual THIS 10HP DRIVE NEEDS 380 ~ 480VAC Three Phase Input. HITACHI SJ200 Series is a Sensorless Vector Constant Torque Drive For more information on 10HP AC or DC Variable Speed Drives EMAIL: sales@driveswarehouse.com OR CALL 1-888-476 5944 For Technical Questions specific to your Application EMAIL: tech@driveswarehouse.com 1.0 Load Type AC Motor 2.0 Rating 2.1 Horsepower 10 2.2 Motor (kW) 7.5 2.3 Capacity (kVA) 13.3 2.4 Output Current (Amps) 16 3.0 Rated Input 3.1 Input Voltage 380 - 480VAC ±10% 3.2 Phase 3 3.3 Frequency 50/60 ±5% 4.0 Rated Output 4.1 Voltage 380 - 4800VAC ±10% 4.2 Phase 3 4.3 Frequency 0.5 - 400 Hz 5.0 Control Method Sine-Wave (PWM) control 6.0 Frequency Range 0.5 - 400 Hz 7.0 Frequency Accuracy 7.1 Digital Command ± 0.01% of the max. frequency 7.2 Analog Command ± 0.2% of the max. frequency 8.0 Frequency Setting Resolution 8.1 Digital 0.1 Hz 8.2 Analog Max. Freq./100 9.0 Volt./Freq. Characteristics Setting available for constant torque, reduced torque, sensorless vector 10.0 Overload Current Rating 150%, 60 seconds 11.0 Acceleration/Deceleration Time 0.1 ~ 3000 sec. (linear/curve, accel./decel.) Second stage accel./decel. setting available 12.0 Braking 12.1 Dynamic Braking Approx. 100% 12.2 DC Braking Operating frequency, time and braking force variable 13.0 Input Signal 13.1 Frequency Setting 13.1.1 Digital Operator Panel Up(1) and Down(2) keys/value setting keys 13.1.2 Potentiometer Analog Setting 13.1.3 External Signal 0 ~ 10 VDC (input impedence 10k ohms), 4 ~ 20 mA (input impedence 250k ohms) Potentiometer: 1k to 2k ohms, variable resistor. The frequency command is the maximum frequency at 9.8V for input voltage 0 - 10 VDC, or at 19.6 mA for input current 4 ~ 20 mA. If this characteristic is not convenient contact Drives Warehouse. 13.2 Forward/Reverse/Start/Stop 13.2.1 Digital Operator Panel Run/Stop (Forward/Reverse run change by command) 13.2.2 External Signal Forward RUN/STOP (1a contact) 13.3 Intelligent Input Terminals FW (Forward run command), RV (reverse run command, CF1~CF4 (multi-stage speed setting), JG (jogging command), 2CH (2-stage acceleration/deceleration command), FRS (free run stop command), EXT (external trip), USP (USP function), SFT (soft lock), AT (analog current input select signal), RS (reset), PTC (thermal protection). 14.0 Output Signal 14.1 Intelligent Output Terminal RUN (running signal), FA1,2 (frequency arrival signal), OL (overload advance notice signal), OD (deviation signal at PID control), AL (alarm signal) 14.2 Frequency Monitor PWM output: Select analog output frequency monitor, analog output current monitor or digital output frequency monitor 15.0 Other Functions AVR function, upper/lower limiter, PID control, carrier frequency change, frequency jump, electronic thermal level adjustment, gain/bias setting function, retry function 16.0 Protective Function Overcurrent, overvoltage, undervoltage, overload, extreme high/low temperature, CPU error, memory error, ground fault detection at startup, internal communication error. 17.0 Environmental Conditions 17.1 Operating Temp. -10 ~ 50?C 17.2 Storage Temp. -10 ~ 70?C 17.3 Humidity 20 ~ 90 % RH (no condensation) 17.4 Vibration 5.9 m/s? (0.6G), 10 ~ 55 Hz 17.5 Location Less than 1000 m of altitude or less, indoors (no corrosive gases or dust) 18.0 Mechanical Properties 18.1 Color Gray 18.2 Height 8.86 inches (220mm) 18.3 Width 7.09 inches (180mm) 18.4 Depth 6.10 inches (155mm) 18.5 Weight (lbs) 8 19.0 Options Remote operator Dynamic braking resistor AC reactor DC reactor Noise filter Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Hitachi
Country of Manufacture	Japan
Model	SJ200-075HFU2
