Hitron Hes18-050300-7 Ac Input115v/230v 2-0.5a 60/50hz Dc Out 5v 3a Power Supply

US $40.99

Israel, default, Israel
Mar 28th

Open on mobile:
QR code

H HiTRON AC/DC EXTERNAL WALLMOUNT & DESKTOP ADAPTER UNIVERSAL INPUT SINGLE OUTPUT 18 WATT FEATURES: o€‚„ UNIVERSAL INPUT o€‚„ DESKTOP FORMAT o€‚„ MEET UNIVERSAL SAFETY STANDARD o€‚„ EMI MEET EN55022 / FCC CLASS B o€‚„ CE MARKING COMPLIANCE GENERAL SPECIFICATION Efficiency: 75-80% typical. Switching Frequency: Fixed 40KHz. Circuit Topology: Fixed Frequency Flyback circuit. Transient Response: Output voltage returns in less than 3mS following a 25% load change. Safety Standard: Meet UL1950/ EN60950 Class II. Class I for WM2,4,5,6G / DT7/PT 2,4,5,7. Power Density: 2.0-2.3Watts / Cubic inch. Operating Temperature: 0A°C to room temperature. 0 to +40 A°C for Japan PSE mark. Storage Temperature: -20 to +85A°C. Temperature Coefficient: 0.04% /A°C typical. Cooling: Free air convection. Construction: Impact resistant thermo-plastic enclosure case. Wallmount or Desktop Format. NOTE: (1) All measurements are at nominal input, full load, and +25A°C unless otherwise specified. (2) Load regulation is measured at 115Vac or 230Vac in percentage to indicate the change in output voltage as the load is varied from half load to full load (A±%). (3) The exact obtainable load regulation depends upon the output cord selected and load current. Upper data are for 6 ft. (2 meters) cord AWG#18 wires. (4)Due to requests in market and advances in technology, specifications subject to change without notice. SPECIFICATION INPUT SPECIFICATION Input Voltage: 90-264Vac typical. Input Connector: Wallmount format:WM1,2(USA/Japan)/WM3(Euro-Stecker)/ WM4(Schuko-stecker)/ WM5(UK)/ WM6, 6G(Australia). Desktop format: IEC320 Inlet Type: DT7-3P or DT8-2P. Mouse Power Pig-tail Type: PT1/2/3/4/5/6/7. Input Frequency: 47-63Hz. Inrush Current: Typical 48A @230Vac or 28A @230Vac by adding thermister. Input Current: 0.4A @115Vac/ 0.17A @230Vac typical. Dielectric Withstand: Meet IEC60950. EMI: Meet EN55022 / FCC Class B. Hold-up Time: 10mS @115Vac/ 40mS @230Vac typical. OUTPUT SPECIFICATION Output Voltage: 5V Output Current: 3A Output Wattage: MAX 18W. Output Connector: Optional. Line Regulation: 0.1% typical. Load Regulation: A±1.5-3.0% typical. Noise & Ripple: 1.0% typical peak to peak. OVP: Built-in Zener diode clamping. Adjustability: Factory set. Overload Protection (OLP): Fully protected against output overload and short circuit. OLP set at about 125-150% rating output wattage. Consult the factory for OLP setting. Import duties, taxes, and charges are not included in the item price or shipping cost. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying. Please note that shipment is usually takes about 3-4 weeks Express shipment is also available but would be charged differently - please feel free to contact me for further details. I would be glad to answer any questions please contact me via my e-mail address

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	HiTRON
MPN	HES18-050300-7
Model	HES18-050300-7
Country of Manufacture	Taiwan, Province of China
