HITTITE HMC524 evaluation board - GaAs MMIC I/Q Mixer / IRM Chip, 22 - 32 GHz, US $99.00 – Picture 0
HITTITE HMC524 evaluation board - GaAs MMIC I/Q Mixer / IRM Chip, 22 - 32 GHz, US $99.00 – Picture 0

Hittite Hmc524 Evaluation Board - Gaas Mmic I/q Mixer / Irm Chip, 22 - 32 Ghz

US $99.00

  • Nis, Serbia, Serbia
  • Feb 13th
Open on mobile:
QR code
GaAs MMIC I/Q Mixer / IRM Chip, 22 - 32 GHz Item is used, but fully funcional passive mixer. General description, copied from the manufacturer's website: The HMC524 is a compact I/Q MMIC mixer which can be used as either an Image Reject Mixer or a Single Sideband Upconverter. The chip utilizes two standard Hittite double balanced mixer cells and a 90 degree hybrid fabricated in a GaAs MESFET process. All data shown below is taken with the chip mounted in a 50 Ohm test fixture and includes the effects of mil diameter x 20 mil length bond wires on each port. A low frequency quadrature hybrid was used to produce a 100 MHz USB IF output. This product is a much smaller alternative to hybrid style Image Reject Mixers and Single Sideband Upconverter assemblies.
“Item is used, but in full working condition.”
Brand Hittite
Model HMC524
