Hmt Horn #4 4l Std Hydraulic Tube Pipe Booster Bender Machine Pines

US $150,000.00

Stone Mountain, Georgia, United States
Jan 31st

Open on mobile:
QR code

HMT #4 Rotary Hydraulic Tube Booster Bending Machine General Info: Stock#: BC-141008 Machine Name: HMT #4 Rotary Hydraulic Tube Booster Bending Machine Condition: Used, Good Brand: HMT Model: 4L STD Year: 2009 Approximate Shipping Weight: N/A Approximate Shipping Dimensions: 6.5' W x 26' L x 4.5' H Location: GA Specifications: • Heavy Duty Single Axis bender which can also be used for conventional bending • Designed to form tight radius (1 x D) thick wall tubes used in the boiler industry using empty bend tooling • Designed to produce the maximum amount of boost pressure while using the least amount of space to grip tube. • The grip from bottom clamping device locks the tube into the pressure die and allows the tube to be forced (boosted) into the bend die, thus reducing wall thinning and ovality. Non Ferrous Tubing up to 25,000 PSI 6" OD x .250 WT Steel Tubing upto 40,000 PSI 6" OD x .165 WT Stainless Steel Tubing up to 60,000 PSI 4.5" OD x .172 WT Steel Pipe IPS up to SCH 80 Pipe 4" Solid Steel Bar up to 3.5" Square Steel Tube up to 4" x .250 WT Max Radius: 24" CLR Max Tube Over Mandrel: 20' Max Degree of Bend: 180 + Overbend Bend Arm Speed: 4 RPM Equipped with: Standard 24" Capacity Straight Clamping Swing Arm Tooling Plate on Die Boss, Deep Seated Die Keyway Steel Slides with Alumabronze Wear Strips HD Solid Steel Clamp Holder with Half Round, Hardened Tooling Bolts HD Solid Steel Pressure Die Holder with Additional CAM Followers 58" Long Follower Bar and Hardened Master Bar All Hydraulic Cylinders are Parker Brand Main Drive Motor - 40 HP 1725 RPM, 480VAC Booster Motor - 30 HP 1725 RPM, 480VAC Parker Hydraulic Pumps and Pressure Control Valves Parker Hydraulic Proportional and Directional Control Valves Parker 3000 PSI Hoses Bijur Lube System Pause Mats 1AXB+ PLC Based Controller Pressure Die Assist Over Head Tie Bar Wiper Base and Holder Additional Info: The machine is currently under power and is ready to be tested. We are currently selling this and a Pines #4 Mandrel Bender as well. There are several dies available that have been shared by both machines. Because of this we are selling each machine without tooling. You will have the option to pick out any available tooling and negotiate a price out with us. Seller Contact Information: Carl Davis 404-933-3804 The Equipment Hub, LLC 1380-A Beverage Dr. Stone Mountain, GA 30083 Are you looking for a different machine than the one listed? Visit our eBay Store to see other machinery options. It is always recommend to come out and inspect the machinery listed before purchase. If you have any specific questions or would like to set up a time to view this piece of machinery feel free to contact the contact person for this listing 7 days a week.

Condition:

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...

Type

Hydraulic
