Honeywell C6097b1028 Gas Pressure Switch

US $75.00

Chanhassen, Minnesota, United States
Jan 29th

Open on mobile:
QR code

Honeywell C6097B1028 Gas Pressure switch Overview Pressure Switches are safety devices used in positive-pressure or differential-pressure systems to sense gas or air pressure systems. Features For use with natural gas, liquid propane (LP) gas, or air. Diaphragm-actuated safety-limit switch. Switch can be wired to turn on alarm. C6097A models break control circuit at setpoint on pressure fall. C6097B models break control circuit at setpoint on pressure rise. Lockout with manual reset and recycle options. Lockout models have external manual reset button. Removable transparent cover protects scaleplate and adjusting knob. Pipe tappings allow selection of positive pressure (air only) or venting connections (NPT mount only). 1/4 in. NPT or flange mount models for direct mounting to Honeywell Integrated Valve Train. Optional switch position indicator lamp available. IP54 enclosure standard. Ranges: 0.4 to 5 in.wc, 3 to 21 in.wc, 12 to 60 in.wc or 1.5 to 7 psi. Surge orifice. Integral vent limiter on all models. Product Specifications ApplicationSafety devices used in positive-pressure or differential-pressure systems to sense gas or air pressure changesDimensions (in.)3 17/32 in. high x 2 23/32 in. wide x 2 23/32 in. deepDimensions (mm)90 mm high x 69 mm wide x 69 mm deepMounting1/4 in. NPT internal threadElectrical RatingsIgnition Transformer: 540 VA, Pilot Valve: 50 VA. Main Valve: 400 VA with 2-1/2 times inrushApprovals, Underwriters Laboratories Inc.Component Listed, MP 2168-8-1Approvals, Canadian Standards AssociationFile # 95329 Certificate 2632-01Electrical ConnectionsScrew terminalsContact Ratings120 Vac Switch Contact-- 3.0 AFL, 18.0 ALR, 5.0 A resistive; 240 Vac Switch Contact-- 3.0 AFL, 18.0 ALR, 5.0 A resistiveOperating Temperature Range (F)-40 F to +140 FOperating Temperature Range (C)-40 C to +60 CApprovals, Swiss REAcceptableApprovals, Factory MutualJI 2D4A1.AFApprovals, OthersCSD-1 AFB: AcceptableOperating Range (psi)3 to 21 in. wcOperating Range (kPa)0.7 to 5.2 kPaDifferential Pressure Range (psi)max. 2.4 in. wc @ min. setpoint; max. 4.2 in. wc @ max. setpointDifferential Pressure Range (kPa)max. 0.60 kPa @ min. setpoint; max. 1.05 kPa @ max. setpoint:Differential TypeSubtractiveSwitch OperationManual ResetSwitching ActionBreak on pressure risePipe ConnectionVent or Low pressure--1/8 in. NPT internal thread

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Honeywell
Model	C6097B1028
