Honeywell E-mon E34-208400-r01kit Class 3400 Meter, Energy Meter

US $999.99

Lemont, Illinois, United States
Aug 2nd

Open on mobile:
QR code

E-Mon D-mon E34-208400-R-06-SP-KIT Class 3400 kWh Submeter, 208V, 400A, NEMA 4X, RTU Modbus TCP/IP Protocol, Single / 2 Phase (2 Element), 2 Split-Core Sensors w/ 2V Out Product Features: Advanced 4-line display showing: kWh kW demand (with peak date & time) Power factor per phase Real-time load in kW Amps per phase Volts per phase On-board set-up option for: Meter date/time IP address Load control settings ID codes for EZ7, Modbus and BACnet RS-485 Protocol Options: E-Mon Energy EZ7 (Standard) Modbus RTU BACnet MS/TP Optional expanded feature package provides additional features: Load control option for load control/shedding Two external meter inputs -- water, gas, BTU, etc. -- stored in channels 5 & 6 Two Pulse outputs (one kWh and one kVARh) 0-2 volt output split-core current sensors allow for enhanced safety and accurate remote mounting of sensors up to 500 feet from meter without power interruption (optional solid-core sensors available) Onboard installation diagnostics and verification system Built-in RS-485 communications capability supports the following connection configurations (or combinations not to exceed 52 devices per channel): Up to 52 Class 3200, 3400 or 5000 meters and/or IDR interval data recorders Cabling can be either daisy-chain or star configuration, 3-conductor, 18-22 AWG, up to 4,000 cable feet total per channel Communications: Built-in communication RS-485 Ethernet Pulse output Optional telephone modem Protocols (*NOTE: Interval data not stored in BACnet or LonWorks units) EZ7 BACnet MS/TP* Modbus RTU BACnet IP* Modbus TCP/IP LonWorks FT-10 (Twisted Pair)* Records kWh & kVARh delivered, kWh & kVARh received in first four channels Data stored in 15-min intervals for up to 72 days or 5-minute intervals for up to 24 days Maintains interval data storage in a first-in, first-out format Compatible with E-Mon Energy software via EZ7 protocol for automatic meter reading, billing and profiling of interval energy data Meter is designed for use on both 3-phase, 3-wire (delta) and 3-phase, 4-wire (wye) circuits Outdoor NEMA 4X polycarbonate enclosure (standard) with padlocking hasp & mounting flanges for indoor/outdoor installation (stand alone) with one 1 1/16" KO on bottom of enclosure Optional industrial grade JIC steel enclosure w/padlocking hasp & mounting flanges for indoor installation with three 1 1/16" KO (3/4" conduit) on bottom of enclosure UL/CUL Listed: Certified by independent test lab to ANSI C12.20 national accuracy standards (+/- 0.2% from 1% to 100% of rated load) MV-90 Compatible (with EZ7 only LF

Condition:	New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...	Brand	E-mon D-Mon
MPN	E34-208400-r01
