Honeywell Hp400ulm 4 Amp 12/24avdc

US $96

Grapevine, Texas, United States
Jun 9th

Open on mobile:
QR code

This unit was pulled from a working installation. No warranty. The HP400ULM is a 12VDC or 24VDC power supply with an HPMOM6 distribution controller to be used with Card Access Systems. It provides 12/24VDC through 6 power-limited outputs. The 6 outputs will switch ON or OFF security devices such as Magnetic Locks, Door Strikes, Magnetic Fire Door Holders, etc. The HPMOM6 offers a choice of two (2) outputs, “Fail Safe or Fail Secure” and a choice of two (2) Fire inputs, N/O or N/C, and Reverse Polarity triggered by the FACP. The Controller also has 2 Trouble/ Alarm dry contact outputs type “Form C”; 1) Power Fail/ PTC Activated, and 2) FACP Triggered. The unit has not been evaluated as elevator equipment, and is not authorized for bell output in Mercantile applications. Application Notice - This Application notice gives instruction to qualified personnel on how to configure the HP-UL series power supply to accept an AC line voltage of 230VAC at 50/60Hz. Be sure to measure ac mains output voltage before performing any conversions on power supply. Data Sheet - (302 KB PDF) Installation Instructions - (945 KB PDF) Drawing - (193 KB DWG) Enclosure Dimensions - (32 KB PDF) UL Listing ALVY.S6677 - Click Here UL Listing APHV.S6677 - Click Here UL Listing UTRZ.S6677 - Click Here CSFM LISTING Replacement Fuse RatingPower Supply AC Line Fuse HP300UL Series 2 Amps, 250V, 5X20MM HP400UL Series 3 Amps, 250V, 5X20MM HP600UL Series 5 Amps, 250V, 5X20MM Specifications - Power Supply Board Input voltage: 120VAC 60Hz; Current: 2.50A max. Output Voltage: 12VDC or 24VDC, jumper selectable; Current: 4.0A continuous output maximum, 3.5A plus battery charger (not supervised). Fail safe dry contact output on AC Failure (within one minute). Built-in charger for sealed lead acid or gel cell type batteries. Instantaneous transfer to stand-by battery on AC failure. Battery presence detection (within 1 minute) Battery low disconnect at 9.90VDC or 19.90VDC. High voltage disconnect at 15VDC or 30VDC. Yellow LED (L3) indication for battery disconnected and battery low. Fail safe dry contact output for Battery trouble (Fail Safe). Battery polarity reversal protection. Thermal overload and short circuit protection. DC output PTC activated indication by Red LED (L2). DC output failure indication by Red LED ( L4 ). AC presence indication by Green LED ( L1 ). DC output indication by Red LED ( L5 ). Battery Leads included. Power Board Dimensions: 6.2”L x 4.7”W x 2.5”H. Enclosure Dimension: 17”L x 13.5”W x 4.75”H. Accommodates two 12 Volt 12AH batteries. When using larger batteries, a UL approved enclosure must be used. UL Listed for Access Control Systems; UL294. UL Listed for Fire Alarm Systems; UL1481. UL Listed for Burglar Alarm Systems; UL603. Specifications - Distribution Board Outputs – 6 Fail Safe or Fail Secure – Each PTC protected output rated 2.5A @ 23C with a maximum of 2.0A @ 49C. – Automatic Yellow LED status indication of activated PTC. – Test push button lights Yellow LED’s to verify their operation. – Red LED for power on indication. Fire Alarm Control Panel Input – Polarity reversing input. – Normally open (NO) or normally closed (NC) supervised input with 2.2K Ohm (EOL) resistor. – Engineering Reset (Optional) normally open (NO) or normally closed (NC) input with 2.2 K Ohm (EOL) resistor. Alarm Outputs – Alarm outputs are Fail Safe – When FACP activation occurs dry contacts activated. – Green LED indication when FACP is activated. – Dry contacts output for power failure to the HPMOM6. Board Dimensions: 5.3" L x 3.5" W x 1.0" H (13.46 cm L x 8.89 cm W x 2.54 cm H).
