Honeywell Ml7425a3013 (ml7425a 3013) Actuator

US $349.00

Bryn Mawr, Pennsylvania, United States
Jan 29th

Open on mobile:
QR code

**NEW** HONEYWELL ML7425A3013 ACTUATOR Description • Easy and quick installation on valves with 1 3/8" bonnet and 3/4" stroke. • No separate linkage required. • Conduit connector standard. • No adjustments required on linkage. • Accurate valve positioning. • Low power consumption. • High close-off ratings. • Force limiting end switches. • Internal manual operator. • Synchronous motor. • Maintenance free. Product Specifications Back To Top Description Direct-Coupled, Linear-Stoke, Valve Actuator Actuator Type Valve Application Type HVAC Torque/Force (lb-in., lbf) 135 lbf Torque/Force (Nm, N) 600 N Fail Safe Mode Stem down on power failure Control Signal 0 to 10 Vdc Control Signal 2 to 10 Vdc Supply Voltage 24 Vac ±15% Number of Internal Auxiliary Switch 0 Switches Yes Medium Temperature (F) 300 F Maximum Medium Temperature (C) 150 C Maximum Feedback 2-10 Vdc Manual operation Manual override winding Spring Return Torque/Force (lb-in., lbf) 135 lbf Spring Return Torque/Force (Nm, N) 600 N Stroke (in.) 3/4 in. Stroke (mm) 20 mm Mounting Directly on V5011/V5013 Globe Valves and VGF Flanged Globe Valves (3/4" or 20mm stroke) Frequency 60 Hz Frequency 50 Hz Spring Return Direction Stem down on power failure Spring Return Timing (Nominal (sec)) 12 sec Timing, Nominal Driving @ 60 Hz (sec) 90 sec Dimensions (in.) 11 1/4 in. high x 5 5/16 in. wide x 6 5/16 in. deep Dimensions (mm) 284 mm high x 135 mm wide x 161 mm deep Weight (lb) 5.1 lb Weight (kg) 2.3 kg Electrical Protection Class I Insulation (24 Vac) Materials ABS-FR Plastic, aluminum yoke Power Consumption (Driving) 12 VA Electrical Connections Screw terminals Cable Entry Conduit connector and one knockout on actuator case Temperature Range, Ambient (F) 14 F to 122 F Temperature Range, Ambient (C) -10 C to +50 C Temperature Range, Storage (F) -40 F to +158 F Temperature Range, Storage (C) -40 C to +70 C Operating Humidity Range (% RH) 5 to 95% RH Ingress Protection Rating IP54 Approvals, Underwriters Laboratories Inc UL94-5V Approvals, CE Recognized Includes 1/2 in. conduit hub Includes 1/2 in. flexible conduit adapter If you are in need of repair for any other Fireye or Honeywell controls, amplifiers, flame scanners, or mod motors, please contact us. We can help. **Photo is for illustrative purposes only, your unit may vary in appearance according to model, or if more than one is available, may not be the exact unit you will recieve.** Please read the small print below for important information regarding purchasing, shipping and out of stock items etc. Thank you A Little About Us We maintain an inventory of over $5.2 million of MRO electrical, HVAC, boiler/burner controls, and process instrumentation. There is no part too small. If you are in need of something regarding heaters, boilers or air-conditioning, SPARE PARTS such as Honeywell charts & thermocouples, Fireye tubes, Foxboro inks & pens, Allen-Bradley relays, Pneumatic HVAC tubing & fittings, Bussman fuses, plus thousands of other parts are readily available directly from our in-depth inventory. As you may gather, our inventory is too large to post all in our store, but we are adding items weekly if you need something not in our Ebay store please feel free to contact us and we will create a listing for it the same day. We sell, repair and rebuild UDC controllers, chart recorders, flame scanners, and Honeywell mod motors. We are the only company in the country that is certified by FACTORY MUTUAL for rebuilt Honeywell® flame safeguard, programmers and controls that meets insurance specs. for hospitals, schools and commercial buildings. We even manufacture our own thermocouples and RTD’s to meet your specification. If you do have old Honeywell programmers, controllers, flame scanners, or modulating motors. Do not throw out you old units!! They may be worth money!! We have a buyback program, email us for information. Our Hours Of Operation Monday-Friday 7am-5pm EST and ship only during these times. Please keep this in consideration when purchasing our products. We will respond to questions and auctions won as soon as possible. All Items will ship within 3 business days. In most cases the item(s) will ship same day. Shipping UPS is our preferred method of shipment for domestic destinations, for international shipments we prefer to use FedEx, they are cheaper than UPS. If you have a UPS or FedEx account that you would rather bill to please let us know. If we determine that the item must be returned, the item must be in the original, undamaged box and we will try to fix it. If we cannot fix the item, we will offer an exchange. Your satisfaction is our number one priority. Please email us for specific details about returns. We ship world-wide. Customer is responsible for all un-expected duties, tax, customs, VAT charges. Terms & Conditions: Surplus: Surplus items are surplus and are not represented by any manufacture. No manufacture warranty or any warranty is expressed or implied. Items are sold as is. If there is a problem with a surplus item, please email us and we will work with you to get the problem resolved. Photos representing these items may not be the exact item that you are purchasing if more than one item is being sold. We guarantee that all items will be in the condition stated above upon receipt. We also offer a non Dead on Arrival (DOA) guarantee. Surplus items that we obtain are in working condition as to the best of our knowledge; please understand that we cannot test all electrical and mechanical items. If an item does not work, contact us first before returning. We have a repair facility on site with experienced technicians that can help with installations or answer questions. Factory New: All products that are noted as factory new are warranted only by the manufactures warranty. No other warranty is expressed or implied. All Names, Logos, Description & other related information are trademarks of their respected companies. If an item fails or does not function properly, contact us for shipping details for return. The customer is responsible for the shipping to be returned to us. All items must be shipped with the undamaged original factory box. All items are always shipped to you double boxed and we expect that they are returned to us this way. Upon receiving of the item in question we will inspect it for damages and asses it to be repaired or exchanged. In rare circumstances we will refund the purchase price. Items that are Factory New are stocked items in our warehouse. Quantities may change without notice. If an item becomes out of stock, they will be back-ordered. Items that will not be back in stock the customer will be notified as soon as possible for refund or an equivalent item. In most cases there are cross-reference items that we will try to find. Rebuilt: Rebuilt units depending which model is purchased, are disassembled, repaired and known to go bad components are replaced, contacts cleaned, bodies repaired and painted if needed. Each circuit board is then resoldered by hand to strengthen the solder joints to extend the life of the unit. Then the product is Quality Control tested by our experienced technicians. Please understand that these units are from damaged older units and may still have slight imperfections even after being rebuilt. Each of our rebuilt units have a 2 year warranty. CAPP/USA® is the only company in the country that is certified by FACTORY MUTUAL for rebuilt Honeywell® flame safeguard, programmers and controls that meets insurance specs. for hospitals, schools and commercial buildings.

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Country of Manufacture

Hungary
