Honeywell Pw6k1r1e Single Door Controller

US $299.00

Colonia, New Jersey, United States
Jan 30th

Open on mobile:
QR code

The PW6K1R1E reader interface provides a network connected, single door with paired reader, PoE based solution to the OEM integrator for interfacing TTL/ Wiegand/RS-485 type readers to door hardware. The on-board twisted pair Ethernet jack with PoE support enables easy installation. A maximum of 16 PW6K1R1E downstream boards can be connected to PW6K1ICE controller board. You can control one physical barrier with PW6K1R1E, using single or paired readers. The first reader port can accommodate a read head that utilizes Wiegand, magnetic stripe, or 2-wire RS-485 electrical signaling standards, one or two wire LED controls, and buzzer control (one wire LED mode only). The second reader port can accommodate a read head that utilizes Wiegand or magnetic stripe signaling, one or two wire LED controls, and buzzer control (one wire LED mode only). You can use two form-C relay outputs for door strike control or alarm signaling.The relay contacts are rated at 5A @ 30VAC/DC, dry contact configuration. Four inputs are provided for monitoring the door contacts, exit push buttons, and alarm contacts. The PW6K1R1E requires power from PoE or local 12VDC. The reader power should be based on peak reader power consumption. The PW6K1R1E may be mounted in a 3-gang switch box; a mounting plate is supplied with the unit. The PW6K1R1E may be mounted in an enclosure; the supplied mounting plate has mounting holes that match the MR50 mounting footprint. Refer to Additional Mounting Information (p. -15) for UL enclosure requirements. The PW6K1R1E has to be installed on the same subnet as PW6101 (i.e., PW6K1ICE) or PW6000. The encryption between both PW6000 and PW6K1ICE, and, PW6101 and PW6K1ICE, is built-in and automatic.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Honeywell
MPN	PW6K1R1E
Model	PW6K1R1E
Type	single door controller
