Honeywell S8610U3009 Universal Intermittent Pilot Ignition Module, US $90.00 – Picture 0
Honeywell S8610U3009 Universal Intermittent Pilot Ignition Module, US $90.00 – Picture 0

Honeywell S8610u3009 Universal Intermittent Pilot Ignition Module

US $90.00

  • United States
  • Jan 29th
Open on mobile:
QR code
Honeywell Ignition Control Board Universal Intermittent Pilot Ignition Module Model S8610U3009    Includes cross reference, instructions, and accessories. Features Replaces over 400 White-Rogers, Robertshaw and Honeywell intermittent pilot ignition modules Provides ignition sequencing, flame monitoring and safety shutoff for intermittent pilot warm air furnaces and heating appliances Provides 100 percent pilot gas shutoff if pilot fails to light; after 6-minute delay, trial for ignition is repeated. Ignition trial/delay sequence is repeated until the appliance lights or call for heat is removed. For use with Natural or LP gas For use in single rod or dual rod/remote sense applications Includes spark cable adapters to allow field replacement of both Honeywell and competitive controls without replacing existing spark cable. Disclaimer: Failure to follow instructions carefully can result in injury or cause damage to the product. Check the ratings given in the instructions to make sure the S8610U module is suitable for your application. The installer must be a trained, experienced service technician. After installation is complete, check out operation as provided in these instructions. Babybluetriton is not responsible for how the product is installed. Installation tips: LED Error Codes: OFF: No call for heat, TH-W does not have 24VAC present Fast Flash: Power up - internal check Heart beat (1/2 sec bright, 1/2 dim cycles): Normal start up, ignition sequence started 4 secs on then x flashes: Device in run mode. "x" = flame current 2 flashes: 5 minute retry delay 3 flashes: Flame failed during run 4 flashes: Flame sensed out of sequence 5 flashes: Damper error. Make sure 24V terminal is not connected if P1 plug is not used 6 flashes: Control internal error 7 flashes: Flame rod shorted to ground 8 flashes: Low secondary voltage supply. Check transformer and AC line IMPORTANT TH-W should be connected to 24VAC from the thermostat 24V GND should be connected to the unswitched leg of 24VAC transformer 24V should NOT be connected if P1 vent damper is not used
