Honeywell Tk-iah061 6 Point Analog Input Module

US $350.00

Santa Barbara, California, United States
Jan 29th

Open on mobile:
QR code

Honeywell Module ANALOG Input , 10VDC 4-20MA MODEL TK-IAH061 Specifications – Traditional I/O Modules TC-IAH061, TK-IAH061 Table 6-6 High Level Analog, 6-Input, Voltage and Current (10 V & 4-20 mA) Module Parameter Specification Number of Points 6 galvanically isolated channels Input Voltage Range (Voltage) Input Current Range (Current) ? 10.50 VDC maximum 0 to 21.0 mA (w/249 ? resistor) Voltage Resolution ± 10.5 volt range 0 to 10.5 volt range 0 to 5.25 volt range Current Resolution 16 bits across each range shown below 343 ?V typical (15 bits + sign) 171 ?V typical 86 ?V typical 0.34 ?A Input Impedance (Voltage) (Current) Greater than 10 M? 249 ? Open Circuit Detection Typical OC Detection Time Upscale reading (Voltage); Zero scale reading (Current) 5 seconds (Voltage); 1 sec (Current) Normal Mode Noise Rejection Common Mode Rejection Greater than 60 dB @ 60 Hz 120 dB @ 60 Hz, 100 dB @ 50 Hz Channel Bandwidth 0 to 15 Hz (-3 db) Settling Time to 5% of Full Scale Less than 80 milliseconds Calibrated Accuracy @ 25?C Better than 0.1% of range (Voltage); better than 0.15% of range including 0.05% sense resistor (Current) Module Update Rate for All Channels 25 ms RFI Immunity Error of less than 2.0% of range at 10 V/m, 27 to 1000 MHz Overvoltage Capability 120 VAC/VDC continuous at room temperature (Voltage); 8 VAC/VDC with on-board current resistor (Current) Input Offset Drift with Temperature 2 ?V/?C typical (Voltage) 8.0 ?V/?C typical (Current) Gain Drift with Temperature 35 ppm/?C typical (Voltage); 45 ppm/?C typical (Current) Power Dissipation 4.3 W max Backplane Current See Module Power Consumption Data, page 46. Isolation Voltage Channel to channel User to system 100% tested at 2546 VDC for 1 second 100% tested at 2546 VDC for 1 second Connection Terminal Blocks TC-TBNH, 20-position terminal block If there is any problem, please let me know and I will do my best to remedy the situation. We greatly appreciate your business. WE INVITE YOU TO BROWSE OUR EBAY STORE We ship these items within 3 days of receiving payment. Business Hours - Mon-Fri, 9am-5pm, EST (closed on major US holidays). Items paid for on the weekend, as well as any questions, offers or comments received, will be addressed on the following business day. International Buyers Please Note: Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying. We do not mark merchandise values below value or mark items as "gifts" - US and International government regulations prohibit such behavior. 801380c-1

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	Honeywell
Type	Input Module
Model	TK-IAH061
Country/Region of Manufacture	United States
MPN	02196180
