Honeywell Universal Gas Valve Part # Vr8345m4302

US $68.00

Medina, Ohio, United States
Feb 13th

Open on mobile:
QR code

Description for Honeywell VR8345M4302 Product Overview: Universal electronic ignition combination gas control for use with direct spark ignition, hot surface ignition or intermittent pilot ignition in 24 Vac, gas-fired appliances, with capacities from 30 to 415 cfh. Product Features: Control includes manual valve, two automatic operators, pressure regulator, pilot adjustment, pilot plug and ignition adapter Replaces virtually any IP, HSI, or DSI gas control For use with natural or manufactured gas or LP gas Includes converter kit to adapt from natural to LP gas Compact size All adjustments and wiring connections accessible from top of control Four-inch swing radius allows easy rotation into position inside the tightest furnace vestibules Clearly marked, keyed terminal block allows quick attachment of wires and IP/DSI/HSI jumper Internal inlet screen blocks contaminants in gas line from entering valve Product Specifications: Description: 24 Vac Dual Direct Ignition/Intermittent pilot Gas Valve with 3/4 in. x 3/4 in. inlet/outlet, standard opening and 3.5 in. wc pressure regulator setting Type: Single Stage Ignition Type: Direct Ignition Ignition Type: Intermittent Pilot Type of Gas: Natural Inlet/Outlet Size (in.): 3/4 in. x 3/4 in. Body Pattern: Straight-through Opening Characteristics: Standard Capacity @ 1 in. p.d.: 300,000 BTU/hr; 30,000 BTU/hr minimum Pressure Ratings (psi): 1/2 psi Pressure Ratings (kPa): 3.5 kPa Pressure Regulator Setting (psi): 3.5 in. wc Pressure Regulator Setting (kPa): 0.87 kPa Pressure Tapping: 1/8 in. NPT with plug Electrical Connections: 1/4 in. quick-connect male terminals Electrical Ratings: 24 Vac Frequency: 60 Hz Temperature Range (F): -40 F to +175 F Temperature Range (C): -40 C to +79 C Mounting: 0 to 90 degrees in any direction from the upright position of the gas control knob, including vertically Dimensions (in.): 5 3/8 in. high x 4 1/16 in. wide x 2 11/16 in. deep Dimensions (mm): 135 mm high x 104 mm wide x 69 mm deep Includes: Two 3/4 x 1/2 in. reducer bushings, natural to LP Conversion Kit Approvals, American Gas Association IAS: AGA Design Certified: File No. L2025007 Approvals, Canadian Gas Association: CGA Design Certified: File No. L2025007 Approvals, Underwriters Laboratories Inc: UL Component Recognized
