Honeywell V4295a1155 2" Solenoid Gas Valve

US $315.99

Brookfield, Connecticut, United States
Jan 29th

Open on mobile:
QR code

Brand new in box... Product Specifications Pipe Size (mm) 51 mm Overview V4295A/V8295A are normally closed and V4295S/V8295S are normally open (vent) solenoid gas valve. Suitable for use on furnaces, ovens, atmospheric burners, commercial water heaters, roof-top make-up air units, power burners, and commercial/industrial boilers. List Price 805.09 Approvals, Control Safety Devices Acceptable Type of Gas Air, natural, manufactured, mixed, and LP Capacity (cfh) 3740 cfh Inlet/Outlet Pressure Tapping 1/4 in. NPT Capacity (m?/hr) 105.9 m3/hr Valve Opening Time less than 1 sec Valve Closing Time less than 1 sec Current (max amps at rated Vac/Hz) 0.540 amps Pipe Size (inch) 2 in. Pipe Size (DN) DN50 Pressure Ratings (psi) 5 psi Pressure Ratings (kPa) 34.5 kPa Body Pattern Straight-through, non-offset Mounting Vertical to 90 degrees from vertical Materials (Body) Die-cast aluminum Voltage 120 Vac Frequency 50 Hz Electrical Connections Screw terminals Operating Temperature Range (F) -40 F to +140 F Operating Temperature Range (C) -40 C to +60 C Dimensions (in.) 9 3/16 in. high x 6 11/16 in. wide x 5 3/8 in. deep Dimensions (mm) 233 mm high x 170 mm wide x 137 mm deep Approvals, Underwriters Laboratories Inc Listed: File No. MH18476, V1, S1 - Guide No. YIOZ Approvals, Canadian Standards Association Certificate No. 158158-1154280, Guide No. C3371-03, 04, 83 Approvals, Factory Mutual Approved: Report No. J.I.OD6A2.AF Approvals, Swiss RE (formerly IRI) Acceptable 2 inch Solenoid Gas Valve, 3740 CFH • V8295A,S are used with 24 Vac controllers. • V4295A,S are used with 120 Vac controllers. • Positive close off of gas flow when de-energized. • High valve spring force allows up to 0.7 psi back pressure at valve seat. • No inlet pressure influence at valve seat. • Inlet pressure changes do not affect ability to close valve. • Low operating noise. • Low rush-in current. • Upstream and downstream taps allows tapping and testing pressure points.
