HP 4192A LF Impedance Analyzer 5Hz -13MHz, Have Been Used by the Seller , US $1,800.00 – Picture 0
HP 4192A LF Impedance Analyzer 5Hz -13MHz, Have Been Used by the Seller , US $1,800.00 – Picture 0

Hp 4192a Lf Impedance Analyzer 5hz -13mhz, Have Been Used By The Seller

US $1,800.00

  • Lawrence Township, New Jersey, United States
  • Jul 17th
Open on mobile:
QR code
HP 4192A LF Impedance Analyzer 5Hz -13MHz.  The 1st and 2nd pictures show series C and R being measured. At first calibration was done with open/short condition of measurement port.  The white and black elements in the photo are capacitor of 1.5nF (below +-5%) and resistor 2kOhm (below +-1% accuracy), connected between alligator clips (red and black). The display shows 1.44nF and 2.1kOhm at 100kHz. Impedance/admittance with loss term can be shown as different expressions, such as |Z|/|Y| with theta, R/G with Q or D, L or C with Q or D, and continuous frequency control by LabView to get response curves on computer,  -- tested and works. -- I did many times of such types of measurement for transducers.
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand HP
Model HP4192A
Frequency Range 5Hz- 13MHz
Product Impedance Analyzer
Measurement Functions C, D, L, R, G, Q, , Z
