Hp 5350a Microwave Frequency Counter Tested And Working On Both Inputs.

US $180

Fort Collins, Colorado, United States
Jun 9th

Open on mobile:
QR code

ArtCraft Electronics is continuing the upgrading of its test equipment. Here is a used 5350A that is working on both inputs. The microwave input is reading a 1296MHz (not quite warmed up) signal source and the HF/VHF/UHF input is reading a Baofeng HT on 446MHz. In both cases I believe the HP rather than the source readout. However, this counter has been used on the bench for several years and has some "character marks". Yes, you absolutely can tell it from new : ). To me that doesn't matter since it does what it's Supposed to. It could use some cleaning up, and the input connectors could be tightened. Only the HP5350A and a power cord are included in this auction. This item is AS-IS and no return. I personally checked it to assure it is working on both inputs. We went to great lengths to assure it was never over driven and you should too. Only the Input 1 and 2 performance tests were done. Here's the specs from the manual. Input 1 Frequency Range 10 Hz to 20 GHz Sensitivity 500 MHz to 12.4 GHz: -25 dBm 12.4 GHz to 20 GHz: -20 dBm Maximum Input +7 dBm Resolution 1 Hz - 1 MHz selectable Input 2 Frequency Range 10 Hz - 525 MHz Sensitivity 50 ohms: 10 MHz to 525 MHz, 25 mV rms 1 M ohms: 10 Hz to 80 MHz, 25 mV rms Maximum Input 50 ohms: +10 dBm 1 M ohms: 1V rms Coupling AC Connector Replaceable fuse, type BNC (female) Impedance selectable 1 M ohms nominal shunted by <70 pF or 50 ohms nominal Resolution Selectable, 1 Hz to 1 MHz High Resolution 1 M ohms mode: 0.001 Hz for <100 kHz input 0.01 Hz for <1 MHz input 0.1 Hz for <10 MHz input 1 Hz for >10 MHz input: 1-second gate The HP 5350A is a CW microwave counter with a measurement range of 10 Hz to 20 GHz. The counter combines high performance measurements with simple, easy-to-use operating procedures. The 5350A is controlled by a single microprocessor that interacts with the counting circuitry to generate data, compute, display measurements, and manipulate measurement data. All measurement modes are selectable via 17 pushbutton keys on the front panel. Selectable functions include Sample Rate and Resolution control for the various measurement modes, and Math functions, such as Offset and Scale, for data manipulation. Additional power and convenience are provided by user-callable test and diagnostic functions, which can be used for troubleshooting, and to obtain additional measurement information. The counter is equipped with memory for saving the front panel setup when the counter is set to Standby mode. All display functions are performed by an LCD, which contains 24 alphanumeric characters (including function annunciators) for displaying both messages and measurement data. Full HP-IB programmability is a standard feature of the 5350A frequency counter. The HP-IB interface provides remote control of measurement functions and data output. All front panel features are available with the HP-IB. Input 1 Frequency range: 500 MHz to 20 GHz Sensitivity (full operating environment) 500 MHz to 12.4 GHz: -25 dBm 12.4 GHz to 20 GHz: -20 dBm Maximum input: +7 dBm Damage level: +25 dBm, peak Impedance: 50 ?, nominal SWR 500 MHz - 10 GHz: Typically, <2:1 10 GHz - 20 GHz: Typically, <3:1 Coupling: DC to 50 ? termination, AC to instrument Accuracy: ±1 count ±time base error x frequency Resolution: Selectable 1 Hz to 1 MHz Connector: Precision Type N female Modes of operation: Automatic, manual FM tolerance Maximum deviation: 20 MHz p-p Maximum FM rate: 10 MHz AM tolerance: Any modulation index as long as the minimum signal level is not less than the sensitivity specification Automatic amplitude discrimination: Automatically measures the largest signal present, as long as that signal is >6 dB above any signal within 500 MHz or >20 dB above any signal within 500 MHz to 20 GHz Acquisition time Automatic mode: Normal FM rate is <200 ms, low FM rate is <1300 ms Manual mode: <40 ms Input 2 Frequency range: 10 Hz to 525 MHz Mode of operation 50 ?: 10 MHz to 525 MHz 1 M?: 10 Hz to 80 MHz Impedance: Selectable 1 M? nominal shunted by <70 pF or 50 ? nominal Maximum input 50 ?: +10 dBM 1 M?: 1 Vrms Coupling: AC Connector: Replaceable fuse, Type BNC female Packing/Shipping to the US mainland is $51.45. Non US customers are served by eBay International shipping and paid by the buyer. I will refund the shipping cost difference if the $51.45 estimate is too high.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	HP
Model	5350A
