Hp 740b Dc Voltage Standard/calibrator Differential Voltmeter

US $170.00

United States, United States
Jun 9th

Open on mobile:
QR code

Up for sale is an HP 740B DC voltage standard differential voltmeter. Unit powers on and will measure voltage as a normal VM (scale directly shows the input) as well as a differential voltmeter (scale shows the difference between the digital display and the input) and will output DC voltage as shown in the last few composite photos. The unit will need to be re-calibrated and likely needs to have the chopper circuit looked over, as that seems to be the culprit for the DC offset when operating the DC voltage standard and differential VM modes. Photos of the DC voltage standard operation had the offset nulled out at 0V output on each range before taking the photo, which was as high as 5V on the 1000V range and as low as 3mV on the 1V range. Overall, the unit looks to be in okay shape and certainly useable once the chopper assembly has been adjusted. The basic input cable I used in the photos for testing will be included with the unit. Product Specifications: The Hewlett-Packard Model 740B is a precision multifunction instrument that operates as a DC standard voltage source, a DC differential voltmeter, a high impedance DC voltmeter and a DC power and voltage amplifier. The instrument is designed for use in both the standards laboratory and the field. --DC Standard-- Output Voltage: 0 to 1.000000 volts in 1uV steps 0 to 10.00000 volts in 10uV steps 0 to 100.0000 volts in 100uV steps 0 to 1000.000 volts in 1mV steps Accuracy: 0.002% of setting + 0.0004% of range Stability: 1ppm of setting + 0.5ppm of range per hour; 5ppm of setting + 1ppm of range per day Temperature Coefficient: >2ppm of setting or 1ppm of range (which ever is greater) per degree C; over 10C to 40C Output Current: 5-50mA, 20mA on 1000V range Noise and Hum: 0.01-1Hz: >1ppm of range; 1Hz to 1MHz: 100dB below full scale or 100uV RMS (which ever is greater) --DC Differential Voltmeter-- Resolution: Null ranges give full scale indication of 0.01% of range. Max resolution 1ppm at full scale. Max usable null sensitivity 1uV full scale. Accuracy: 0.005% of reading + 0.0004% of range + 1uV Stability: 1ppm/hour, 5ppm/day Temperature Coefficient: >2ppm of reading + 1uV per degree C, over 10C to 40C Remember, pictures are part of the description: if it’s not shown it’s not included. We ship FAST, usually same day or next day morning. (Depends on listing closing time and receipt of payment.)

“Will need to be recalibrated. Has dings and scuffs from previous use.”

Brand	HP
MPN	740B
Model	740B
Country/Region of Manufacture	United States
