HP 8005B Pulse Generator | Source impedance: 50 ohms ± 10% | Max output: 1OV, US $3175 – Picture 0
HP 8005B Pulse Generator | Source impedance: 50 ohms ± 10% | Max output: 1OV, US $3175 – Picture 0

Hp 8005b Pulse Generator | Source Impedance: 50 Ohms ± 10% | Max Output: 1ov

US $3175

  • 75081, United States
  • Jun 4th
Open on mobile:
QR code
   HP 8005B Pulse Generator | Source impedance: 50 ohms ± 10%  | Max output: 1OV    Item Details Operating & Service Manual The Model 80058 is a versatile 20 MHz pulse generator that can deliver up to 10 volts positive and, simultaneously, 10 volts negatiVe into a 50 ohm load from a selectable source impedance. Provision is made for external and manual triggering, synchronous and asynchronous gating, a positive trigger output and TTL output of 4.6 volts across an open circuit for positive or negative logic. Repetition rate is variable over the range 0.3 Hz to 20 MHz, alternatively, in double pulse mode 10 MHz simulating 20 MHz or, in square wave mode, 0.15 Hz to 10 MHz. Pulse delay (with respect to the trigger output} is variable over the range< 100 ns to 3 s. Pulse width is variable over the range 25 ns to 3 s with a normal mode duty cycles of> 80% and 100% in complement mode. Transition times (pulse rise and fall) are variable from < 10 ns to 2 s with a rise and fall lor fall to rise} ratio of up to 30:1. Shipping Information  Shipping includes ground only, other methods will require additional cost. Return Policy Hassle-free returns, 14 days money back or item exchange, you pay return shipping. Disclaimer Shipping includes ground only; other methods will require additional cost. We recognize that an ARTICLE may have numerous different configurations. We want you to make an informed decision therefore, we will make the effort to give you as much information as resources permit.   Some markings such as serial numbers and/or other identifying marks may vary. Please let us know if there is a particular device date code or marking that works best for you. We will continue to work hard to get you what you need. That is our pledge. Please let's Make It a "Win-Win". 100% Satisfaction Guaranteed. Get the item you ordered or get your money back. Covers your purchase price and original shipping. Thanks for Shopping! GreenEagleLogistics 102/105
