Hp 8015a / Agilent 8015a - 50mhz Pulse Generator W/opt: 02

US $495.00

San Diego, California, United States
Jun 9th

Open on mobile:
QR code

HP 8015A / Agilent 8015A - 50MHz Pulse Generator w/OPT: 02 ID 50099 The HP 8015A is a 50 MHz pulse generator that features dual outputs - each capable of delivering pulses up to 16 V in amplitude. When the outputs are combined (A + B mode), up to 30 V is available. The 8015A is easy to use - the front panel layout is clear and unambiguous. Controls are positioned so that parameters are easily identified and invalid combinations of parameters can be avoided. Delay, double pulse, and square wave modes of operation are available. A feature of the 8015A is the B Del mode where channel B output is delayed with respect to channel A output. This can be combined with A + B mode so that complex and 3-level waveforms can be synthesized. The external input has a threshold level variable between +1 V and -1 V with 50 ? input impedance and variable between +10 V and -10 V with 500 ? input impedance. A push button permits manual simulation of input signals for all external modes of operation. Pulse transition times: Minimum to 0.5 s in four ranges Linearity: For transition times>30 ns, maximum deviation from a straight line between the 10% and 90% points is less than 5% of pulse amplitude Manufacture Description: Overshoot and ringing: ±5% of pulse amplitude, possibly increasing to <±10% at minimum amplitude •Preshoot: <5% of pulse amplitude •Pulse top perturbations: Droop <5% of pulse amplitude •Pulse width: < 10 ns to 1 s in four ranges •Width jitter: <0.1% + 50 ps •Pulse delay: 20 ns (+25 ns fixed) to 1 s •Delay jitter: <0.1 % + 50 ps •1Hz to 50MHz repetition rate, , 1ns to 1s width, 20ns to 1s delay, Two independent ±16V output, •Additional TTL output, Remote control and counted burst options, Complex waveforms. •Option 002 Burst Mode, •Burst length 1-9999 pulses, selectable. •Pulse repetition rate: 1 Hz to 40 MHz •Burst trigger: Trigger input •Minimum Burst Separation: 200 ns •MEETS MILITARY STANDARDS ID 50099 KR-SR2

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	AGILENT / HP / KEYSIGHT
MPN	8015A
Model	8015A W/OPT NO 02
Country/Region of Manufacture	Germany
