Hp 8566b Spectrum Analyzer 100hz - 22ghz With Interconnect Cables 30-day Warraty

US $6000

Santa Ana, California, United States
May 31st

Open on mobile:
QR code

You're Purchasing a Used; "HP 8566B Spectrum Analyzer 100Hz - 22Ghz With Interconnect Cables" with 30-Day Warranty. Accesories Included: Interconnect Cables Description: The HP 8566B, is a high-performance spectrum analyzers for bench and ATE system use. The HP 8566B is the highest performance analyzer, with extendable frequency range from 100 Hz to 2.5 GHz. The Analyzer is designed around its own internal bus and controlled by its own microcomputer to yield significant improvements in operational and data processing features, as well as flexibility under computer control. Each analyzer has 16K bytes of user RAM for storing trace data, instrument states, or custom downloadable programs (DLPs). Performance: The exceptional frequency stability of both the HP 8566B makes measurements with 10 Hz resolution bandwidths possible. This narrow resolution bandwidth yields sensitivities to -135 dBm in both instruments. Excellent frequency stability, sensitivity, and frequency-reference accuracy combine to allow very accurate measurement of small signals in the presence of larger ones. Usability: The instrument control settings are conveniently notated on the CRT for easy reference. Functions are activated by pressing a front-panel key, then selecting the function value using the knob, step keys, or numeric keyboard. To maintain a calibrated display, certain functions are automatically coupled in the analyzer. For example, resolution bandwidth, video bandwidth, and sweep-time are automatically adjusted by the instrument when the frequency span is reduced. Up to four tunable display markers are available to aid in measuring and analyzing signals. Two markers can be used to make relative measurements by displaying their amplitude and frequency difference. Marker information allows you to step between evenly spaced portions of a spectral display (such as signal harmonics) or "zoom-in" on a selected portion of the spectrum. Analyzer control settings can also be saved in the non-volatile memory of the analyzer. Different operators can recall these settings to make consistent, repeatable measurements. Versatile CRT Display and Plotting Capabilities: All displayed information resides in the analyzer's digital memory, which refreshes the CRT at a flicker-free rate. Multiple traces can be displayed to measure residual FM or drift, or to conduct real-time surveillance over a wide frequency range. By adding an HP-IB plotter, a hard-copy of all information on the display of the analyzer can be made for analysis, documentation, or presentation. Plots can be produced directly or with the aid of a controller. Custom Programming of Soft-keys: Custom measurement routines can be created to meet your specific requirements. These programs can be created on an external controller or from the front-panel controls of the instrument and then stored in the non-volatile memory of the analyzer. Custom programming allows you to create complex measurement routines that can be stored and executed using a single soft-key. This capability makes the analyzer a custom instrument that is more efficient for your specific tasks. Warranty: 30-Day Warranty upon delivery. Payment: Payment is Due Immediately Through PayPal Upon Purchase. FedEx Shipping: Item will be shipped 1-2 days after payments is received. Local Pickup: Buyer must make arrangements prior to Pickup. Re-Stocking Fee: Buyer is subject to pay a 25% fee if item is returned.
