HP Agilent 16950A 68 Ch Logic Analysis Module, 600 MHz State, 4GHz Timing Zoom, US $400 – Picture 0
HP Agilent 16950A 68 Ch Logic Analysis Module, 600 MHz State, 4GHz Timing Zoom, US $400 – Picture 0

Hp Agilent 16950a 68 Ch Logic Analysis Module, 600 Mhz State, 4ghz Timing Zoom

US $400

  • Lake Forest, California, United States
  • Jun 3rd
Open on mobile:
QR code
The 16950A has many key features and specifications that make it stand out. It offers both timing analysis and state analysis capabilities. For timing analysis, it has a 4GHz timing zoom with 64K memory and 1.2 GHz / 600 MHz conventional timing with deep memory. For state analysis, it has state clock rates up to 600 MHz and data rates up to 800 Mb/s. The module also has automated threshold/sample position setup to ensure accurate measurements on high-speed buses and simultaneous eye diagrams on all channels to quickly identify problem signals. The HP Agilent 16950A is tested and guaranteed to work, and comes with a 14-day warranty. If you're a California resident, be sure to add 8% CA State Sales Tax to your purchase. Overall, this module is a great choice for those looking for a flexible and customizable logic analysis solution. When considering how to configure your system, the 16950A has 68 channels per module and can be combined with up to 5 modules for 340 channels. It also has selectable memory depths ranging from 256K to 64M, with memory depth upgrade options available. The module is compatible with 90-pin logic analyzer probes, which can be ordered separately, and is suitable for use with 16900 Series modular logic analyzers. The HP Agilent 16950A is a logic analysis module with 68 channels, 4GHz timing zoom, and 600 MHz state. This module is part of the Keysight Technologies, Inc. 16900 Series logic analysis systems, which are known for their modularity and expandability. It allows you to purchase only the capability you need and then add on as your needs evolve.
