Hp Agilent 8112a Pulse Generator

US $200.00

  • Roseville, California, United States
  • Jan 29th
Open on mobile:
QR code
HP Agilent 8112A Pulse Generator This auction is for a nice, non- working HP Agilent 8112A Pulse Generator.  Comes with the power cord, but no other items.  Fails self test wtih E13 Fail Width Timing test.  Sold As-IS for parts.  No Returns for any reason. Features & Description: 50 MHz, 5 ns, 16 V p-p (into 50 Ohm) Full pulse capability Small size HP-IB Modulation The 8112A is a fully programmable 50 MHz pulse generator with 5 ns transitions and 32 V p-p (into open circuit) max output amplitude. All pulse parameters are variable including delay and double pulse spacing. Besides the comprehensive trigger modes, external modulation capabilities extend applicability; upper level, width, period and delay-modulated signals are available. These can be combined with the trigger modes so that complex real-life signals like modulated bursts are simulated easily. Step response and trigger hysteresis measurements require fast transitions or sawtooth signals as obtained in the HP 8112A's linear transition mode-either fixed 5 ns or variable fro 6.5 ns. The new cosine transitions, also variable from 6.5 ns, mean that band-filtered signals are now just as simple to obtain. Sensitive devices are protected by programming output limits and the upper level can be controlled by the device supply. Also, constant energy or constant width can be programmed. Dual channel operation is feasible by operating HP 8112A's in a master/slave combination. For simple operation a green button gives error-free settings. A new softkey operating concept plus detailed error recognition make the HP 8112A's powerful versatility easy to handle. Complete manual is available here.  _gsrx_vers_526 (GS 6.6.6 (526))
