Hp Agilent 8505a Display Only Tested Good

US $725.00

Manchester, New Hampshire, United States
Jan 29th

Open on mobile:
QR code

YOU ARE BIDDING ON A USED HP AGILENT 8505A NETWORK ANALYZER DISPLAY ONLY WITH OPT 05 The 8505A is a high performance RF network analyzer operating over thekHz to 1.3 GHz frequency range. It accurately and easily measures complex impedance, transfer functions and group delay of coaxial components and semiconductors. Because both magnitude and phase are measured, it is possible to completely characterize the linear behavior of either active or passive networks. THE DISPLAY WAS TESTED W/ OUR 8505A SYSTEM AVL ON ANOTHER SALE AND IS WORKING. THE DISPLAY COULD BE BRIGHTER BUT IT IS NOT BUT IT WORKING AND WE OFFER A DOMESTIC DOA WARRANTY WHICH MEANS ITEMS SOLD OUTSIDE THE USA ARE SOLD AS IS W/O RETURNS. LET US KNOW IF YOU HAVE ANY QUESTIONS. THANKS FOR LOOKING. SPEC LIST: Frequency Characteristics Frequency Range 500 kHz to 1.3 GHz in three ranges; 500 kHz to 13 MHz, 500 kHz to 130 MHz and 500 kHz to 1.3 GHz Swept Frequency Accuracy ± 1% of range for linear sweep CW Frequency Accuracy ± 2 counts ± time-base accuracy Frequency Stability Better than ± 0.01% of reading ± 0.01% of frequency range over 10 minutes after warm-up. Frequency Counter Characteristics Frequency counter measurements are made at any one of five continuously variable marker positions without interrupting the swept RF signal. Resolution (least significant digit) Frequency Range (MHz) 0.5 to 1.3 0.5 to 130 0.5 to 1300 10 ms Sweep time 10 kHz 100 kHz 1 MHz 100 ms Sweep time 1 kHz 10 kHz 100 kHz > 1 second Sweep time 100Hz 1 kHz 10 kHz Counter Accuracy ± 2 counts ± time-base accuracy. Marker Frequency Accuracy ± 0.002% of scan width ± counter accuracy. Measured in CW ± DF Time-base Accuracy ± 5 ppm ± 1 ppm/°C ± 3 ppm/90 days Output Characteristics Output Power Range +10 dBm to -72 dBm. Attenuator Accuracy ± 1.5dBm over 70 dB range. Vernier Accuracy ± 1 dB. Leveling ± 0.5 dB from 500 kHz to 1.3 GHz Impedance 50?; ? 16 dB return loss at -10 dBm output level (<1.38 SWR). Residual FM Frequency Range (MHz) 0.5 to 13 0.5 to 130 0.5 to 1300 Residual FM 50 Hz rms 200 Hz rms 2 kHz rms Bandwidth 20 Hz-1 kHz 20 Hz-1 kHz 20 Hz-10 kHz Harmonics > 25 dB below main signal at +10 dBm output level. Sub-harmonics and Spurious Signals below -50 dBm at +10 dBm output level. General Characteristics Sweep Modes Linear Full, Log Full, Start/Stop 1, Start/Stop 2, Alternate, CW ± DF, and CW. Sweep Times 10 ms to 100 s in decade ranges. Trigger Modes auto, line sync., signal scan or external sync. RF Output Connector Type N female RECEIVER Frequency Range 500 kHz to 1.3 GHz Input Characteristics Input Channels three channels (R, A, and B) with 100 dB dynamic range. Damage Level +20 dBm or ? 50 V dc. Noise (10 kHz BW): -110 dBm from 10 to 1300 MHz; -100 dBm from 2 to 10 MHz; -95 dBm from 0.5 to 2 MHz. Impedance 50?: ? 20 dB return loss (<1.22 SWR). Typically > 26 dB return loss (<1.11 SWR). Magnitude Characteristics Absolute Frequency Response (A, B, R) ± 1.5 dB Ratio Frequency Response (A/R, B/R) ± 0.3 dB from 0.5 MHz Dynamic Accuracy ± 0.01 dB/dB from -20 to -40 dBm; ± 0.2 dB from -10 to -50 dBm; ± 0.5 dB from -50 to -70 dBm; ± 1.0 dB from -70 to -90 dBm; ± 2.0 dB from -90 to -100 dBm; ± 4.0 dB from -100 to -110 dBm. Reference Offset Range ± 199.9 dB Reference Offset Accuracy ± 0.03 dB ± 0.003 dB/dB of offset Marker Measurement Resolution 0.01 dB over any < 10 dB range; 0.1 dB over any ? 10 dB range. CRT Display Resolution 0.1 dB to 20 dB/division in 1, 2, 5 sequence. Phase Characteristics Frequency Response ±3° from 500 kHz to 750 MHz; ±5° from 750 MHz to 1.3 GHz. Range ±180° Accuracy ±0.01°/degree for ±170°; ±0.01°/degree ±0.5° for ±180° Dynamic Accuracy (in 10 kHz Bandwidth) ±0.02° /dB from -20 to -40 dBm; ±0.5° from -10 to -50 dBm; ±1° from -50 to -70 dBm; 3° from -70 to -90 dBm. Crosstalk see amplitude crosstalk specification. Reference Offset Accuracy ±0.3° ±0.5° of offset. Marker Measurement Resolution ±0.1° over < 100° range and 1° for ? 100° range. CRT Display Resolution 1° to 180° per division in 8 steps. Polar Characteristics Frequency Response, Dynamic Response, Reference Offset and Marker Measurement specifications are the same as magnitude and phase characteristics. CRT Display Accuracy Actual value is within less than 3 mm circle of the displayed value. Tracking Between dB Offset Controls and Polar Full Switch Positions

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Unit Type	Complete Systems & Mainframes
Manufacturer	Agilent / HP
Analyzer Type	Network Analyzers
