Hp/agilent 8563e Microwave Spectrum Analyzer 006, 007, 008 26.5 Ghz

US $10,299.99

Phoenix, Arizona, United States
Feb 25th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! HP/Agilent 8563E Microwave Spectrum Analyzer with Options 006, 007, and 008 - 30 Hz to 26.5 GHz Sweeps! Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from HP/Agilent and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit will be fully tested and guaranteed to work for 30-days, parts and labor, excluding freight. The Unit's Serial Number Tag Reads: Model Number: 8565E Serial Number: 3515A03370 Options: 006, 007, 008, 8ZE Link to the Datasheet: HP 8560E-Series Spectrum Analyzer Datasheet Link to the Manual: HP 8560E & EC Series Spectrum Analyzer Manual Link to the Quick Reference Guide: HP 8560E & EC Series Spectrum Analyzer Quick Reference Guide Link to the Quick Calibration Guide: HP 8560E & EC Series Spectrum Analyzer Calibration Guide Option Description: Opt. 006: 30 Hz to Freq. Coverage Opt. 007: Digitized Fast Time-Domain Sweeps Opt. 008: Signal Identification Key Features: Continuous 30 Hz to 26.5 GHz sweeps Resolution bandwidths of 1 Hz to 100 Hz digitally implemented for measurement speed Low phase noise and wide dynamo range Precision timebase and 1 Hz counter resolution Adjacent channel power, channel power, carrier power and grated video measurements standard MIL-T-28800 rugged Description: The HP 8560 E-series portable spectrum analyzers offer the measurement capabilities and performance traditionally found only in larger, more expensive benchtop analyzers. These spectrum analyzers combine outstanding phase noise, sensitivity, 1 Hz resolution bandwidths and wide dynamic range in a MIL-rugged package built to withstand harsh environmental conditions. HP 8563E Microwave Spectrum Analyzer: The HP 8563E extends the outstanding features and capabilities of the HP 8560 E-series RF spectrum analyzers into the microwave frequency range. The HP 8563E has a standard frequency range of 9 kHz to 26.5 GHz (preselected from 2.75 GHz to 26.5 GHz), with optional low-end frequency coverage to 30 Hz. The image-enhanced, double-balanced harmonic mixer of the HP 8563E achieves noise-figure performance similar to that of a fundamentally-mixed front end. Frequency Specifications: Frequency Range (Internal Mixing): 9 kHz to 26.5 GHz; 30 Hz to 26.5 GHz (Option 006) Frequency Range (External Mixing): 18 GHz to 325 GHz in 12-wave guide bands Frequency Reference Accuracy: Temperature Stability: ±1 x 10-6 Aging (Per Year): ±1 x 10-7 Setability: ±1 x 10-8 Warmup (Nominal): 5 minute ±1 x 10-7; 15 minute ±1 x 10 -8 Frequency Readout Accuracy (N = L0 Harmonic): Span > 2 MHz x N: ±(freq. readout x freq. ref. accuracy + 5% x span + 15% x RBW + 10 Hz) Span < or = to 2 MHz x N: ±(freq. readout x freq. ref. accuracy +1% x span +15% x RBW + 10 Hz) Marker Count Accuracy (S/N > or = to 25 dB): ± (marker freq. x freq. ref. accuracy + 2 Hz x N + 1 LSD) Counter Resolution: Selectable from 1 Hz to 1 MHz Frequency Span: Range: 0 Hz, 100 Hz to maximum frequency Sweep Time: Range: Span = 0 Hz: 50 µs to 6,000 s Span > or = to 100 Hz: 50 ms to 100 ks Accuracy: Sweep Time > 30 ms: ±1% digital Sweep Time < 30 ms: ±10% analog; ±0.1% digital (Option 007) Sweep Trigger: Delayed, free run, single, line, video, external Resolution Bandwidth: Range (-3 dB): 1 Hz to 1 MHz in a 1, 3, 10 sequence and 2 MHz Accuracy: 1 Hz to 300 kHz: ±10% 1 MHz: ± 25% 2 MHz: +50%, -25% Selectivity (-60 dB/-3 dB): RBW > or = to 300 Hz: < 15:1 RBW < or = to 100 Hz: < 5:1 Video Bandwidth Range: 1 Hz to 3 MHz in a 1, 3, 10 sequence Noise Sidebands (Center Frequency < or = to 1 GHz): 100 Hz Offset: < -18 dBc/Hz 1 kHz Offset: < -97 dBc/Hz 10 kHz Offset: < -113 dBc/Hz 100 kHz Offset: < -117 dBc/Hz Residual FM (zero span): < 1 Hz p-p in 20 ms; < 0.25 Hz p-p in 20 ms (nominal) Amplitude Specifications: Range: Displayed average noise level to +30 dBm Maximum Safe Input Level: Average Continuous Power: +30 dBm (1W, input atten. > or = to 10 dB) Peak Pulse Power (< 10 µs pulse width and < 1% duty cycle): +50 dBm (100 W, input atten. > or = to 30 dB) DC Volts: < ±0.2 V (dc-coupled) 1 dB Gain Compression: 10 MHz to 2.9 GHz: mixer level < or = to -5 dBm 2.9 GHz to 6.5 GHz: mixer level < or = to 0 dBm > 6.5 GHz: < or = to -3 dBm Displayed Average Noise Level (0 dB input atten., 1 Hz RBW1): 30 Hz Frequency: -90 dBm 1 kHz Frequency: -105 dBm 10 kHz Frequency: -120 dBm 100 kHz Frequency: -120 dBm 1 to 10 MHz Frequency: -140 dBm 10 MHz to 2.9 GHz Frequency: -149 dBm 2.9 to 6.5 GHz Frequency: -148 dBm 6.5 to 13.2 GHz Frequency: -145 dBm 13.2 to 22.0 GHz Frequency: -149 dBm 22.0 to 26.5 GHz Frequency: -139 dBm Spurious Responses: Mixer Level: Distortion: General Spurious: -40 dBm < (-75 + 20 log N) dBc Second Harmonic Dist. 20 MHz to 1.45 GHz7 -40 dBm <-79 dBc 1 MHz to 1.45 GHz -20 dBm <-72 dBc 1.45 GHz to 3.25 GHz2 -10 dBm <-72 dBc 1.45 GHz to 2.0 GHz4 -10 dBm <-85 dBc 2 GHz to 6.6 GHz7 -10 dBm <-100 dBc 2.0 GHz to 13.25 GHz5 -10 dBm <-100 dBc 2.0 GHz to 20 GHz6 -10 dBm <-90 dBc 20 GHz to 25 GHz3 -10 dBm <-90 dBc 3rd Order Intermodulation9: 20 MHz to 2.9 GHz9 -30 dBm <-82 dBc 1 MHz to 2.9 GHz -30 dBm <-78 dBc 2.9 GHz to 6.5 GHz -30 dBm <-90 dBc 6.5 GHz to 26.5 GHz -30 dBm <-75 dBc Images: 10 MHz to 26.5 GHz -10 dBm <-80 dBc Multiple and Out-of-Band Responses: 10 MHz to 26.5 GHz -10 dBm <-80 dBc Notes: 1: 10 Hz RBW (Min. RBW with Option 103) add 10 dB to noise floor 2: HP 8561E only 3: HP 8565E only 4: HP 8563E/64E/65E only 5: HP 8563E only 6: HP 8564E/65E only 7: Except HP 8561E 8: For HP 8561E: -145 dBm 9: TOI reference to single tone Residual Responses (>200 kHz, N=1): or = to 300 Hz): 0 to +1 V full scale LO Sweep I FAV Output (shared BNC female, 2 kΩ): Amplitude (LO Sweep): 0 to 10 V, no load Blanking/Gate Output: Shared BNC female, 50 Ω, TTL output External/Gate Trigger Input (shared BNC female, > 10 kΩ): Settable to high TTL or low TTL HP-IB: IEEE-488 bus connector Interface Functions: SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT0, C1, C28, E1 General Specifications: Environmental: Military Specs: Per MIL-T-28800 Calibration Interval: Two years Warmup Time: 5 minutes in ambient conditions Temperature: -10°C to +55°C (operating); -51° to +71°C (non operating) Humidity: 95% @ 40°C for five days Rain Resistance: Drip-proof at 16 liters/hour/sq. ft. Altitude: 15,000 ft. (operating); 50,000 ft. (non operating) Pulse Shock (Half Sine): 30 g for 11 ms duration Transit Drop: 8-inch drop on six faces and eight corners Electromagnetic Compatibility: Conducted and radiated interference in compliance with CISPR Pub. 11 (1990). Meets MIL-STD-461C, part 4, with certain exceptions. Power Requirements: 115 VAC Operation: 90 to 140 V rms, 3.2 A rms max., 47 to 440 Hz 230 VAC Operation: 180 to 250 V rms, 1.8 A rms max., 47 to 66 Hz Maximum Power Dissipation: 180 W Audible Noise (Nominal): < 5.0 Bels power at room temp. (ISO DP7779) Size (w/o handle, feet, cover): 337 mm W x 187 mm H x 460 mm D (13 1/4" x 7 3/8" x 18 1/8") Weight (Carrying, Nominal): 20 kg (44 lb) For More Pictures Please Click the Following: Picture 2 - Front View Picture 3 - Back View Picture 4 - Side View Picture 5 - Display with Options Menu Picture 6 - Serial Number Tag For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $50.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 07/20/11 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

“HP/Agilent 8563E Microwave Spectrum Analyzer 006, 007, 008 26.5 GHz”

Brand	HP
Model	8563E
