Hp / Agilent 8620c Sweep Oscillator 86241a Rf Section

US $620.00

Manchester, New Hampshire, United States
Jan 29th

Open on mobile:
QR code

YOU ARE BIDDING ON A USED HP AGILENT 8620C SWEEP OSCILLATOR WITH 86241A RF SECTION SOME DETAILS: 8620C Sweep Oscillator Mainframe The 8620C Sweep Oscillator Mainframe, with more than 15 solid-state plug-ins available (sold separately), can provide >10 mW of leveled output power from 3 to 18.6 GHz. Plug-In sweep bandwidths range from 3 to 350MHz to the wide band 2 to 18.6 GHz module. With appropriate plug-ins, four separate bands and their respective frequency scales can be selected. Start-Stop sweep points may be set from 1% to 100% of band, up or down scale, at sweep rates from 10 msec to 100 sec per sweep. DeltaF sweeps, at the same rates, from 1% or 10% of band may also be made. CW, continuous wave, makes the sweeper a signal generator, which may be modulated, or allows manual sweeps for frequency calibration. Other sweep modes include automatic, manual, externally triggered, single sweep, and remotely programmed. A marker, selected by the CW/Marker control, may be adjusted to any point on the band, and indicated by either amplitude or intensity Frequency: 3.2GHz to 6.5GHzSweep functions: Start-Stop, Delta, CW, Remote Programmed. Sweep modes: auto, line, external. Sweep time: 10 msec to 100 sec. Sweep output: direct coupled, 0 to 10 V. Modulation: Internal AM 1 kHz; External FM based on RF unit. Option 001 = Programmable Source ,011 GPIB. THIS UNIT HAS BEEN TESTED AND COMES WITH A DOMESTIC DOA WARRANTY. LET US KNOW IF YOU HAVE ANY QUESTIONS. THANKS FOR LOOKING. Froo www.froo.com | Froo Cross Sell, Free Cross Sell, Cross promote, eBay Marketing, eBay listing Apps, eBay Apps, eBay Application

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Agilent / HP
MPN	8520c w/ 86241A RF Section
Model	sweep generator
Country/Region of Manufacture	United States
