Hp Agilent 8922m + 83220e Gsm/dcs/pcs Ms Multi-band Rf Test System Set

US $4,000.00

United States
Jan 29th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! HP 8922M GSM Multi-Band RF Test Set with the 83220E Extender Comes with a set of manuals and everything you see in the pictures. If you don't see it, you probably wont get it. Specifications are from HP and may include options/revisions not in this unit. Guaranteed to work for 30-days, parts and labor, excluding freight. Checked the frequency response 1999.999 MHz. This unit will have to be upgraded to the latest software from the factory (3/19/04). Right now it is 2000 instead of 2004. Information from the Units: 8922M Serial Number: 3639U01725 Firmware Version: C.01.10 83220E Serial Number: 3741U02301 Link to Data Sheet: http://www.mhzelectronics.com/ebay/hp_8922_series_gsm.pdf Description: The Agilent 8922M is a powerful GSM RF Test Set designed for high volume manufacturing. Flexible, but easy to use, its extensive feature set makes it the ideal choice when speed, accuracy and repeatability are key to minimizing production costs. When used in conjunction with an Agilent 83220A/E, the frequency range of the Agilent 8922M is extended to cover the DCS1800 and PCS1900 bands. The Agilent 8922P, based on the Agilent 8922M and Agilent 83220E, enhances the Agilent 8922M by adding Dual-band assignment capability. Features: Emulates GSM Base Station Easy to use; one button call set-up from power on Fast, accurate and repeatable measurements GSM Phase II compatible (including fast burst BER measurements and Enhanced Full-rate Speech) High Speed Circuit Switched Data (HSCSD) E-GSM and Dual-band assignment capability Electronic attenuators for increased reliability Tool kit of instruments including spectrum and audio analyzers Full control over GPIB Agilent 83212D software provides full automatic testing of a GSM mobile phone More flexible and 25% faster than the Agilent 8922S The first choice for GSM mobile service and repair: Troubleshoot and find faults fast with the Agilent Technologies 8922S GSM MS service test set. Use it to reduce false failures with a test set that combines versatility with ease-of-use. Serving the needs of the GSM mobile manufacturer: Maximize production throughput and minimize the cost per test with the 8922M GSM MS test set. It offers the highest speed of test in its class while guaranteeing accurate and repeatable measurements. Expand to DCS1800 or PCS1900: Add the 83220A/E test set to test DCS1800 and PCS1900 mobiles. (this is included) GSM functionality Specifications: Bit/frame error rate measurements: Class Ia, Ib, and Class II bits in both raw and residual form. MS power output level control: 0 to 15 with RF analyzer auto adjust. Broadcast channel capability: BCCH + CCCH or BCCH + CCCH + SDCCH/4. Control channels (SDCCH, FACCH, SACCH): BCCH + CCCH, BCCH + CCCH + SDCCH/4, SDCCH/8 (nonhopped), SACCH/FACCH. Call control capabilities: BS originated cell (FS/EFS), MS originated call (FS/EFS), MS camp-on, BS call disconnect, MS call disconnect. Traffic channels: TCH (FS/EFS)–HSCSD Timing: Auto, manual, uplink-downlink and offset measurement. Hopping: Two independent, user definable MA tables with offsets. Speech encoding/decoding: Full rate speech. Speech echo mode: User selectable delay 0 to 5 seconds. Measurement coordination: Flexible control of burst type, ARFCN and timeslot. SACCH MEAS result: RXLEV, RXQUAL and timing advance. Agilent 8922M Test Set: Measurement Speed: 10 to 20% increase in throughput Multi-burst measurement capability: Yes GSM phase II power levels: Yes E-GSM frequency bands: Yes Electronic attenuator: Yes SMS cell broadcast: Yes Peak carrier power meter range: -5 to +41 dBm RF generator power level range: -14 to -127 dBm Burst-by-burst BER measurement: Yes Screen freeze facility: Yes Flash firmware upgrades by GPIB: Yes IMSI attach/detach function: Yes Transmitter tester: Transmitter measurements such as power versus time, modulation phase and frequency error, and burst timing are made using a fast DSP analyzer. There’s also an accurate peak power meter to perform the GSM average Tx power measurement, taking sam-ples only during the active part of the burst. Receiver tester: Receiver testing is done using an accurate 0.3 GMSK source. The wide dynamic range allows for low-level sensitivity measurements and high power tests to check for receiver saturation. Mobile receiver sensitivity is measured by making bit-error-rate measurements on Class Ia, Ib and II bits in either raw or residual form. Spectrum analyzer: The optional spectrum analyzer completes the array of GSM measurements which can be made. It provides high dynamic range pulse on/off ratio measurements and output RF spectrum tests. The spectrum analyzer also makes an excellent diagnostic tool for tracing signals and finding problems. Toolkit (not sure if this is included or not): The full-featured tool-kit includes a power meter, CW RF synthesizer, audio synthesizer, frequency vounter, DVM, audio analyzer, oscilloscope and DSP Analyzer. These tools can be configured to measure just about any signal a GSM phone can produce, whether on a call or in test-mode. Base station emulator: The GSM base station emulator creates a test network to which the mobile can camp and make calls. The emulator is capable of causing a ‘simple camp’ so that receiver and transmitter functions can be verified separately. A speech coder is present to allow functional voice testing. A variety of basic call processing features test the mobile as if it were in a real network. These features include hopped traffic channels, call origination and termination (both mobile and base station), hand-overs, channel assignments, Tx power control commands and a choice of control channel configurations. Automatic software (not sure if this is included): The optional automatic test software is easy to use, fast and simple to configure. With the flexibility to allow test sequences to be created and saved in minutes, automatic test software personalizes the test set for each part of the incoming inspection or repair process. Agilent 8922M Tests: Associated GSM Specifications 11.10 Tests Transceiver frequency bands II.2.1.1 Transceiver RF channels and numbering II.2.1.2 Transceiver frequency hopping II.2.1.3 Transceiver spurious emissions? II.2.2 Tx peak transmitted power II.3.3 Tx RF spectrum due to switching? II.3.4 Tx RF spectrum due to modulation? II.3.4 Tx amplitude envelope (top 30 dB, and -70 dBc point) II.3.3 Tx phase error and frequency error II.3.1 Rx sensitivity II.4.2 Rx usable input level range II.4.3 Rx co-channel rejection? II.4.4 Rx adjacent channel rejection (same frequency/different timeslot) (different frequency/same timeslot)? II.4.5 Rx intermodulation rejection? II.4.6 Rx blocking and spurious response II.4.7 Timebase tuning range Production test 1 The 8922S/M have limited capability for this measurement (< 1 GHz, and limited resolution bandwidth and spans). 2 The 8922S/M test set use a 3 pole resolution bandwidth filter to make these measurements. 3 8922M test set only; an additional RF source, such as the 8657 Option 022 0.3 GMSK signal generator, is required to make this measurement. 4 An additional CW RF source (frequency range of 100 kHz to 12.75 GHz, no modulation needed) is required to make this measurement. Link to Enlarged Picture #1: HP 8922 System - Front View Link to Enlarged Picture #2: HP 8922 System - Rear View Link to Enlarged Picture #3: HP 8922 System Screen - Up-Close For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $100.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. Prior to shipment I need to know the following information: (1) Are you the end-user of this item? (2) If you are not the ultimate end-user of the item, please state the ultimate end user's name. (3) What is the ultimate country destination? If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 12/10/05 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition	Seller refurbished : An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details.
Seller Notes	“Guaranteed to work for 30-days, parts and labor, excluding freight. Checked the frequency response 1999.999 MHz.”
