Click Here. Double your traffic. Get Vendio Gallery - Now FREE! HP/Agilent E4418A/EPM-441A EPM Digital Power Meter Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from HP/Agilent and may vary slightly due to upgrades, options, or revisions this unit may or may not have. This unit is currently installed in a big system but will be removed and fully tested prior to shipment. It is guaranteed to work for 30-days, parts and labor, excluding freight. The Unit's Display Reads: Model Number: E4418A Serial Number: US38261468 Option: 003 Main Firmware: A1.02.00 Main Firmware Date: Mar. 9, 1998 Bootrom Revision: A.01.00 DSP Revision: A.01.10 Gate Array Revision: A.01.03 Option 003: Supplied parallel rear panel sensor input(s). The power reference oscillator output is also on the rear panel. Link to the Datasheet: HP/Agilent E4418A/EPM-441A Power Meter Manual Link to the User Manual: HP/Agilent E4418A & E4419A Power Meter Service Manual Link to the Programming Manual: HP/Agilent E4418A & E4419A Power Meter Programming Manual Description: The E4418A is a low-cost, high-performance, single-channel, programmable power meter. It is fully compatible with the 8480 series and the E-series power sensors (except the E9320A family). Depending upon which sensor is used, the E4418A can measure from -70 dBm to +44 dBm at frequencies from 100 kHz to 110 GHz. Designed for bench and automatic test equipment (ATE) use, the E4418A makes fast (up to 200 readings per second with E-series sensors), accurate and repeatable power measurements. Fast measurement speed (up to 200 readings per second, over the GPIB, with E-series sensors) Speed improvement of x2 using the 8480 series power sensor (compared to 437B) No range-switching delays with 8480 series sensors, and only one fast-range switch point with E-series sensors High-resolution display with backlighting for a wide viewing angle of displayed data Save and recall of up to 10 instrument states GPIB connector for remote control of all functions Code compatibility with 437B Conformity to CE and CSA standards Specifications: Frequency Range: 100 kHz to 50 GHz and 75 GHz to 110 GHz, power sensor dependent. Power Range: -70 dBm to +44 dBm (100 pW to 25 W), power sensor dependent Power Sensors: Compatible with all HP 8480 series power sensors and HP ECP-series power sensors. Single Sensor Dynamic Range: ECP-Series: 90 dB maximum 8480 Series: 50 dB maximum Display Units: Absolute: Watt or dBm Relative: Percent or dB Display Resolution: Selectable resolution of: 1.0, 0.1, 0.01, and 0.001 dB in logarithmic mode, or 1, 2, 3 and 4 significant digits in linear mode Default Resolution: 0.01 dB in logarithmic mode, 3 digits in linear mode Accuracy: Absolute: ±0.02 dB (Logarithmic) or ±0.5% (Linear). (Refer to the power sensor linearity specification in your power sensor manual to assess overall system accuracy). Relative: ±0.04 dB (Logarithmic) or ±1.0% (Linear). (Refer to the power sensor linearity specification in your power sensor manual to assess overall system accuracy). Zero Set (Digital Settability of Zero): Power sensor dependent (refer to Tabel 5-1 in user's manual). For HP ECP-series power seniors, this specification applies when zeroing is performed with the sensor input disconnected from the POWER REF. Power Reference: Power Output: 1.00 mW (0.0 dBm). Factory set to ±0.7%. Accuracy: ±1.2% worst case (±0.9% rss( for one year. Frequency: 50 Hz nominal SWR: 1.05 maximum Connector: Type N (f), 50 Ω Measurement Speed: Over the HP-IB, three measurement speed modes are available as shown, along with the typical maximum measurement speed for each mode: Normal: 20 readings/second x2: 40 readings/second Fast: 200 readings/second, for HP ECP-series power sensors only. Note: Maximum measurement speed is obtained using binary output in free run trigger mode. Rear Panel Connectors: Recorder Output: Analog 0-1 Volt, 1 kΩ output impedance, BNC connector. HP-IB: Allows communication with an external controller. Ground: Binding post, accepts 4 mm plug or bare-wire connection. Line Power: Input Voltage Range: 85 to 264 VAC, automatic selection Input Frequency Range: 47 to 63 Hz Power Requirement: approximately 50 VA (14 Watts) Environmental Characteristics: General Conditions: Complies with the requirements of the EMC Directive 89/336/EEC. This includes Generic Immunity Standard EN 50082-1:1992 and Radiated Interference Standard EN 55011:1991/CISPR11:1990, Group 1 - Class A. Operating Environment: Temperature: 0°C to 55°C Maximum Humidity: 95% at 40°C (non-condensing) Minimum Humidity: 15% at 40°C (non-condensing) Maximum Altitude: 3,000 meters (9,840 feet) Location: For use indoors. Storage Conditions: Storage Temperature: -20°C to +70°C Non-Operating Maximum Humidity: 90% at 65°C (non-condensing) Non-Operating Maximum Altitude: 15,240 meters (50,000 feet) Dimensions: 212.6 mm W x 88.5 mm H 348.3 mm D (8.5" x 3.5" x 13.7") - exclude front and rear panel protrusions. Weight: 4.0 Kg (8.8 lb) Safety: Conforms to: EN61010-1: 1993/IEC 1010-1:1990+A1/CSA C22.2 No. 1010-1:1993 EN60825-1: 1994/IEC 825-1: 1993 Class 1 Low Voltage Directive 72/23/EEC Remote Programming: Interface: HP-IB interface operates to IEEE 488.2. Command Language: SCPI standard interface commands. HP 437B code compatible. HP-IB Compatibility: SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP1, DC1, DT1, C0 Non-Volatile Memory: Battery: Lithium Polycarbon Monoflouride, approximate lifetime 5 years at 25°C For Domestic Customers: Packaging, handling, and order processing included in shipping in all domestic shipments as quoted by the shipping calculator. For International Customers there is a $25.00 minimum for packaging, handling, and order processing. International shipping to be determined by destination. If you have any questions please call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 07/30/12 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
