Hp Hewlett Packard Agilent 8594e 9khz-2.9ghz Spectrum Analyzer+opt 041+101+140

US $1,749.99

Anaheim, California, United States
Mar 24th

Open on mobile:
QR code

What You'll get: HP Hewlett Packard Agilent 8594E 9KHz-2.9Ghz Rack-Mount Spectrum Analyzer 041+101+140 Options (1) Detachable Power Cord Other Accessories that are Not pictured or mentioned under "What You'll Get" are Not included Please visit our eBay Store for more similar items ! Testing: Pulled from a working environment. Unit tested to power on and all functions work as expected, Unit was then professionally inspected for full functionality. Guaranteed Working! Cosmetics: Pictures are of the actual unit. Light scratches and scuffs from typical use, but very clean overall and cosmetically sound, please reference pictures for cosmetics. Taken from the Internet: 8594E: 10 kHz to 2.9 GHz; 1 kHz min (Opt 130) Range Span = 0 Hz or > 10 kHz 20 ms to 100 s Span = 0 Hz (Opt 101) 20 µs to 100 s Accuracy 20 ms to 100 s ± 3% 20 µs to < 20 ms (Opt 101) ± 2% Sweep Trigger free run, single, line, video, external Resolution Bandwidths 1 kHz to 3 MHz (3 dB) in 1, 3, 10 sequence; 9 kHz and 120 kHz (6 dB) EMI bandwidths. Option 130 adds 30, 100, and 300 Hz (3 dB) bandwidths and 200 Hz (6 dB) EMI bandwidth. Accuracy ± 20% Selectivity (characteristic) -60 dB/-3 dB: 3 to 10 kHz, 15:1 100 kHz to 3 MHz, 15:1 1 kHz, 30 kHz, 16:1 -40 dB/-3 dB: 30 Hz to 300 Hz, 10:1 Video Bandwidth Range 30 Hz to 1 MHz in 1, 3 sequence (1 Hz to 1 MHz with Opt 130) STABILITY Noise Sidebands (1 kHz RBW, 30 Hz VBW, sample detector) > 10 kHz offset from CW signal =-90 dBc/Hz + 20 log N > 20 kHz offset from CW signal =-100 dBc/Hz + 20 log N >30 kHz offset from CW signal = -105 dBc/Hz + 20 log N Residual FM HP 8591E 1 kHz RBW, 1 kHz VBW =250 Hz p-p in 100 ms 30 Hz RBW, 30 Hz VBW = 30 Hz p-p in 300 ms HP 8593E, 8594E, 8595E, 8596E 1 kHz, RBW, 1 kHz VBW = (250 X N) Hz p-p in 100 ms 30 Hz RBW, 30 Hz VBW =(30 X N) Hz p-p in 300 ms System Related Sidebands (> 30 kHz offset from CW signal) = -65 dBc + 20 log N Comb Generator (HP 8593E, 8596E) 100 MHz fundamental frequency; ± 0.007% frequency accuracy AMPLITUDE Amplitude Range Displayed average noise level to +30 dBm HP 8591E Opt 001 Displayed average noise level to +75 dBmV Maximum Safe Input (input attenuator @ 10 dB) Average continuous power +30 dBm (1O) HP 8591E Opt 001 +75 dBmV (0.4 O) Peak Pulse Power HP 8591E +30 dBm (1 O) HP 8591E Opt 001 +75 dBmV (0.4 O) HP 8593E, 8594E, 8595E, 8596E +50 dBm (100 O) for < 10 µs pulse width and < 1% duty cycle, input atten > 30 dB DC HP 8591E 25 Vdc HP 8591E Opt 001 100 Vdc HP 8593E, 8594E, 8595E, 8596E 0 V (dc-coupled); 50 V (ac-coupled) Gain Compression (> 10 MHz) =0.5 dB (total power at input mixer = -10 dBm) Displayed Average Noise Level (input terminated, 0 dB atten, 30 Hz VBW or 1 Hz VBW with Opt 130, sample detector 30 Hz RBW 1 kHz RBW HP 8591E 400 kHz to 1 MHz =-130 dBm =-115 dBm 1 MHz to 1.5 GHz =-130 dBm =-115 dBm 1.5 GHz to 1.8 GHz =-128 dBm =-113 dBm HP 8591E Opt 001 1 MHz to 1.5 GHz =-78 dBmV =-63 dBm 1.5 GHz to 1.8 GHz =-76 dBmV =-61 dBm HP 8594E 400 kHz to 5 MHz =-122 dBm =-107 dBm 5 MHz to 2.9 GHz =-127 dBm =-112 dBm HP 8595E 400 kHz to 2.9 GHz =-125 dBm =-110 dBm 2.75 to 6.5 GHz =-127 dBm =-112 dBm HP 8596E 400 kHz to 2.9 GHz =-125 dBm =-110 dBm 2.75 to 6.5 GHz =-127 dBm =-112 dBm 6.0 to 12.8 GHz =-115 dBm =-100 dBm HP 8593E 400 kHz to 2.9 GHz =-127 dBm =-112 dBm 2.75 to 6.5 GHz =-129 dBm =-114 dBm 6.0 to 12.8 GHz =-117 dBm =-102 dBm 12.4 to 19.4 GHz =-113 dBm =-98 dBm 19.1 to 22 GHz =-107 dBm =-92 dBm HP 8593E Opt 026 19.1 to 26.5 GHz =-102 dBm =-87 dBm Spurious Responses Second Harmonic Distortion 5 MHz to 1.8 GHz (HP 8591E) < -70 dBc for -45 dBm tone at input mixer 10 MHz to 2.9 GHz (HP 8593E) < -70 dBc for -40 dBm tone at input mixer > 10 MHz (HP 8594E, 8595E, 8596E) < -70 dBc for -40 dBm tone at input mixer > 2.75 GHz (HP 8593E, 8595E, 8596E) < -100 dBc for two -30 dBm tones at input and > 50 kHz separation Third-order Intermodulation HP 8591E (5 MHz to 1.8 GHz) < -70 dBc for two -30 dBm tones at input and > 50 kHz separation HP 8593E, 8594E, 8595E, 8596E (> 10 MHz) < -70 dBc for two -30 dBm tones at input and > 50 kHz separation Other Input-related Spurious (± 30 kHz offset, -20 dBm tone at input mixer) HP 8591E, 8594E, 8595E, 8596E < -65 dBc HP 8593E < -65 dBc (applied freq =18 GHz); < -60 dBc (applied freq =22 GHz) Residual Responses (input terminated, 0 dB attenuation) 1 MHz to 1.8 GHz (HP 8591E Opt 001) < - 38 dBmV 150 kHz to 1.8 GHz (HP 8591E) < -90 dBm 150 kHz to 6.5 GHz (HP 8593E, 8595E, 8596E) < -90 dBm Display Range Log Scale 0 to -70 dB from ref level is calibrated: 0.1, 0.2, 0.5 dB/div and 1 to 20 dB/div in 1 dB steps; 8 div displayed Linear Scale 8 divisions Scale Units dBm, dBmV, dBµV, V, O Marker Readout Resolution Log Scale 0.05 dB Linear Scale 0.05% of ref level Fast Time Sweep for Zero Span (Opt 101 or 301, 20 µs to 20 ms) =1 GHz 0.7% of ref level for linear scale > 1 GHz 1.0% of ref level for linear scale Reference Level Range Same as amplitude range Resolution ± 0.01 dB for log scale; ± 0.12% of ref level for linear scale Accuracy ± 0.3 dB at -20 dBm 0 to -59.9 dBm: ± (0.3 dB + 0.01 X dB from -20 dBm) Frequency Response (10 dB input attenuation) Absolute (referenced to 300 MHz CAL OUT) HP 8591E, 8594E ± 1.5 dB HP 8595E ± 1.5 to ± 2.0 dB HP 8596E ± 1.5 to ± 2.5 dB HP 8593E ± 1.5 to ± 5.0 dB (preselector peaked) Relative Flatness (referenced to midpoint between highest and lowest frequency response deviations) HP 8591E, 8594E ± 1.0 dB HP 8595E ± 1.0 to ± 1.5 dB HP 8596E ± 1.0 to ± 2.0 dB HP 8593E ± 1.0 to ± 2.0 dB (preselector peaked) Calibrator Output Amplitude -20 dBm ± 0.4 dB; + 28.75 dBmV ± 0.4 dB, HP 8591 Opt 001 Resolution Bandwidth Switching Uncertainty (ref to 3 kHz RBW, at ref level) 3 kHz to 3 MHz RBW ± 0.4 dB 1 kHz RBW ± 0.5 dB 30 Hz to 300 Hz RBW ± 0.6 dB Log to Linear Switching ± 0.25 dB at ref level Display Scale Fidelity Log Incremental Accuracy (0 to -60 dB from ref level) ± 0.4 dB/4 dB Log Maximum Cumulative (0 to -70 dB from ref level) 1 kHz to 3 MHz RBW ± (0.3 + 0.01 X dB from ref level) 30 to 300 Hz RBW ± (0.4 + 0.01 X dB from ref level) Linear Accuracy ± 3% of ref level GENERAL SPECIFICATIONS Temperature Operating 0° to +55°C Storage -40° to +75°C EMI Compatibility Conducted and radiated interference CISPR Pub. 11 and Messempfaenger Postverfuegung 526/527/79 Audible Noise < 37.5 dBA pressure and < 5.0 Bels power (ISODP7779) Power Requirements On (line 1) 90 to 132 V rms, 47 to 440 Hz 195 to 250 V rms, 47 to 66 Hz Power Consumption < 500 VA; < 180 O Standby (line 0) Power Consumption < 7 O User Program Memory (nominal) 121 KB nonvolatile RAM Data Storage (nominal) Internal 50 traces; 8 states External Memory Cards HP 85700A (32 KB), 24 traces or 32 states HP 85702A (128 KB), 99 traces or 128 states Video Cassette Recorder (VCR) Continuous video recording of display supported through composite video output Size (nominal, without handle, feet, or cover) 325 mm W X 163 mm H X 427 mm D Weight 14.5 kg (HP 8591E): 16.4 kg (HP 8593E, 8594E, 8595E, 8596E) Option 010 AND 011 BUILT-IN TRACKING GENERATORS Option 010 (50 O) is available for all HP 8590 Series spectrum analyzers except the HP 8592D. Opt 011 (75 O) is available for the HP 8590D and 8591E only. Frequency Range Opt 010 100 kHz to 1.8 GHz (HP 8590D, 8591E); 300 kHz to 2.9 GHz (HP 8593E, 8594E, 8595E, 8596E) Opt 011 1 MHz to 1.8 GHz (HP 8590D, 8591E) Output Level Range Opt 010 0 to -15 dBm (HP 8590D); 0 to -70 dBm (HP 8591E); -1 to -66 dBm (HP 8593E, 8594E, 8595E, 8596E) Opt 011 +42.8 to -27.8 dBm V (HP 8590D); +42.8 to -27.2 dBmV (HP 8591E) Resolution 0.1 dB Absolute Accuracy ± 1.5 dB (HP 8590D, 8592D); ± 1.0 dB (HP 8591E); ± 0.75 dB (HP 8593E, 8594E, 8595E, 8596E) Vernier Range 15 dB (HP 8590D); 10 dB (HP 8591E); 8 dB (HP 8593E, 8594E, 8595E, 8596E) Accuracy ± 1.0 dB (HP 8590D); ± 0.25 dB (HP 8591E); ± 0.8 dB (HP 8593E, 8594E, 8595E, 8596E) Output Flatness ± 1.75 dB (HP 8590D, 8591E); ± 2.0 dB, > 10 MHz (HP 8593E, 8594E, 8595E, 8596E) Spurious Output Harmonic Spurs 0 dBm + 42.8 dBmV output, < -20 dBm (HP 8590D); < -25 dBc (HP 8593E, 8594E, 8595E, 8596E) Nonharmonic Spurs < -30 dBc Dynamic Range (characteristic; max output level -TG feed-though) Opt 010 106 dB (HP 8590D, 8591E); 108 dB (HP 8594E, > 400 kHz); 111 dB (HP 8595E, 8596E, > 400 kHz); 113 dB (HP 8593E, > 400 kHz) Opt 011 100 dB Power Sweep Range Option 010 -15 dBm to 0 dBm (HP 8590D); -75 dBm to 0 dBm (HP 8591E); -66 dBm to -1 dBm in 8 dB increments (HP 8593E, 8594E, 8595E, 8596E) Option 011 -27.8 dBmV to +42.8 dBmV (HP 8590D); -32.2 to +42.8 dBmV (HP 8591E) Resolution 0.1 dB Top of Page Specifications apply to either 8590D or 8592D analyzer unless otherwise noted. FREQUENCY Frequency Range HP 8590D 50 O 9 kHz to 1.8 GHz 75 O (Opt 001) 1 MHz to 1.8 GHz HP 8592D 9 kHz to 22 GHz HP 8592D (Opt 026) 9 kHz to 26.5 GHz Band LO Harmonic = N Center Frequency 0 1 9 kHz to 2.9 GHz 1 1 2.75 to 6.5 GHz 2 2 6.0 to 12.8 GHz 3 3 12.4 to 19.4 GHz 4 4 19.1 to 22.0 GHz 4 4 (Opt 026) 19.1 to 26.5 GHz Frequency Reference (HP 8590D Opt 013) Aging ± 2 X 10-6/year Temperature Stability ± 5 X 10-6 Initial Achievable Accuracy (start, stop, center, marker) HP 8590D ± (5 MHz + 1% of freq span) HP 8590D Opt 013 ± (freq readout X freq ref error + span accuracy + 1% of span + 20% of RBW + 100 Hz) HP 8592D ± [(5 X N) MHz + 0.01% of center freq + 2% of freq span] Marker Count Accuracy (HP 8590D Opt 013) Span =10 MHz ± (marker freq X freq ref error + counter resolution + 100 Hz) Span > 10 MHz ± (marker freq X freq ref error + counter resolution + 1 kHz) Counter Resolution Span =10 MHz, selectable from 10 Hz to 100 kHz; span > 10 MHz, selectable from 100 Hz to 100 kHz Frequency Span Range HP 8590D 0 Hz (zero span), 10 kHz to 1.8 GHz HP 8592D 0 Hz, [50 X N] kHz to 19.25 GHz Resolution Four digits Accuracy ± 3% of span Sweep Time Range 20 ms to 100 s Accuracy ± 3% Sweep Trigger Free run, single, line, video, external Resolution Bandwidth (characteristic) 1 kHz to 3 MHz (3 dB) in 1, 3, 10 sequence ± 20% accuracy; 9 kHz and 120 kHz (6 dB) EMI bandwidths Video Bandwidth Range 30 Hz to 1 MHz in 1, 3, 10 sequence Stability Noise Sidebands (1 kHz RBW, 30 Hz VBW and sample detector) =-95 dBc/Hz + 20 log N at > 30 kHz offset from CW signal System-related Sidebands =-65 dBc + 20 log N at > 30 kHz at offset from CW signal Comb Generator Frequency (HP 8592D) 100 MHz fundamental freq Accuracy ± 0.007% AMPLITUDE Amplitude Range HP 8590D, 8592D Displayed average noise level to +30 dBm HP 8590D Opt 001 Displayed average noise level to +75 dBmV Maximum Safe Input Level (input attenuator 10 dB) Average Continuous Power HP 8590D, 8592D +30 dBm (1O) HP 8590D Opt 001 +75 dBmV (0.4O) Peak Pulse Power HP 8590D +30 dBm (1O); +75 dBmV (0.4O) (Opt 001) HP 8592D +50 dBm (100O) for < 10 µs pulse width and < 1% duty cycle, input atten 30 dB dc HP 8590D 25 Vdc; 100 Vdc (Opt 001) HP 8592D 0 Vdc Gain Compression (> 10 MHz) = 0.5 dB (total power at input mixer = -10 dBm) Displayed Average Noise Level (input terminated, 0 dB atten, 1 kHz RBW, 30 Hz VBW) HP 8590D = -115 to =-113 dBm; =-63 to =-61 dB,V (Opt 001) HP 8592D =-112 to =-92 dBm; =-112 to = -87 dBm (Opt 026) Spurious Responses Second Harmonic Distortion ( >5 MHz) HP 8590D < -70 dBc for -45 dBm tone at input mixer HP 8592D 10 MHz to 2.9 GHz < -70 dBc for -40 dBm tone at input mixer 2.75 GHz < -100 dBc for -10 dBm tone at input mixer (or below DANL) Third-order Intermodulation HP 8590D Distortion > 5 MHz < -70 dBc for two -30 dBm tones at input mixer and > 50 kHz separation Other Input-related < -65 dBc at 30 kHz offset, for -20 dBm tone at input mixer HP 8592D Distortion > 10 MHz < -70 dBc for two -30 dBm tones at input mixer and > 50 kHz separation Other Input-related < -65 dBc at 30 kHz offset, for -20 dBm tone at input mixer, =18 GHz; < -60 dBc for -20 dBm tone at input mixer, =22 GHz Display Range Log Scale 0 to -70 dB from ref level is calibrated; 0.1, 0.2, 0.5 dB/div and 1 to 20 dB/div in 1 dB steps; 8 div displayed Linear Scale 8 divisions Scale Units dBm, dBmV, dBµV, V, O Marker Readout Resolution 0.05 dB for log scale; 0.5% of reference level for linear Reference Level Range Same as amplitude range Resolution 0.01 dB for log scale; 0.12% of ref level for linear Accuracy ± 0.3 dB @ -20 dBm 0 dBm to -59.9 dBm: ± (0.3 dB + 0.01 X dB from -20 dBm) Frequency Response (10 dB input attenuation) Absolute (referenced to 300 MHz CAL OUT) HP 8590D ± 1.5 dB HP 8592D (preselector peaked in band > 0) ± 1.5 to ± 5.0 dB Relative ± 1.0 dB, referred to midpoint between highest and lowest frequency response deviations HP 8590D ± 1.0 dB HP 8592D (preselector peaked in band > 0) ± 1.0 to ± 2.0 dB HP 8590D Opt 001 +28.75 dBmV ± 0.4 dB Resolution Bandwidth Switching Uncertainty (ref to 3 kHz RBW, at ref level) ± 0.4 dB for 3 kHz to 3 MHz RBW; ± 0.5 dB for 1 kHz Log to Linear Switching ± 0.25 dB at ref level Display Scale Fidelity Log Incremental Accuracy ± 0.4 dB/4 dB, 0 to -60 dB from ref level Log Maximum Cumulative ± (0.4 dB + 0.01 X dB from ref level), 0 to -70 dB from ref level Linear Accuracy ± 3% of ref level GENERAL SPECIFICATIONS Same as for HP 8590E-Series. Policies & Definitions: Shipping Most items ship out within 1-2 BUSINESS days after the payment clears. We allow local pick up. Handling fee of $9.99 and CA tax will apply. We combine shipping to save you money if the items can be combined and shipped safely. We offer a combined shipping discount of $3 for each additional item purchased. Free shipping offers do NOT apply to Puerto Rico, Alaska, Hawaii and international transactions Definitions: GUARANTEED WORKING MEANS : The item is guaranteed working as long as we receive it back within 30 days from the purchase date. We will replace the item at no additional cost if the item is DOA. If replacement is Not available, we will refund the purchase price. Please bid accordingly AS-IS MEANS: The item is sold AS-IS Where is. This means that the buyer acknowledges that the item may or may Not be working and that the item may or may Not be complete and the buyer is willing to accept the risk. Please bid accordingly Shipping and handling cost is Not refundable under any circumstances and the buyer is responsible for any additional shipping cost. please bid accordingly. Return Policy Every item we sell is carefully inspected before it is shipped and is tested to the best of our ability. If merchandise is Not as described please keep all packing materials, brochures, paperwork, etc. and contact us immediately after your package arrives for a return authorization claim number or to file a claim with the carrier on your behalf. * All claims MUST be made within 3 days of receipt of order *Shipping charges will not be refunded * Non-defective returned items are subject to a 30% restocking fee. Ebay's Required Disclosure for Medical Equipment: "The sale of Some medical equipment may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If the item is subject to FDA regulation, I might verify your status as an authorized purchaser of this item before shipping of the item." The shipping weight for this item is approximately 40 LB -14364 -b21r Powered by SixBit's eCommerce Solution

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	HP
Model	8594E
