Hubbell Circuit-lock Fused Mechanical Interlock Device Cat# Hbl460mif12w

US $1,349.24

Albuquerque, New Mexico, United States
Jan 29th

Open on mobile:
QR code

Hubbell Circuit-Lock Fused Mechanical Interlock Device Cat# HBL460MIF12W ITEM DESCRIPTION: Excellent condition - no packaging. It has no signs of use other than small scratches on casing from not being boxed but I am listing as used as I am not sure. ACCESSORIES: Manual included. No cables, or other accessories. GENERAL INFORMATION & SPECIFICATIONS: MSRP = $3799.00 Mechanical Interlock Device Standard IEC Service Style Standard Mechanical Interlock Items Complete Unit Amperage 60A Voltage 125/250V Poles and Wires 3 Pole, 4 Wire Terminal Accommodations #2 To #10 AWG copper wire only Color Orange & Gray Mating Plug HBL460P12W Horsepower Rating 705 Base VALOX Handle Valox Shaft Seal Neoprene Top VALOX Conduit Hub Zinc, Watertight: 1 1/4" NPT Shaft Brass Enclosure Inserts Brass Enclosure Hinge Pins Nickel Plated Brass Hinge Spring Stainless Steel (300 series) Mounting Screws Stainless Steel (300 Series) Assembly Screws Stainless Steel (300 series) Gaskets Neoprene Fuse Types UL Listed Class "J", CSA Certified HRCI-J Certification UL Listed, CSA Certified Dielectric Withstand Voltage Withstands 3,000V AC Max Working Voltage 600V AC RMS Current Interrupting Certified for current interrupting at full rated current. Short Circuit Withstand Suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical amperes at the voltage rating of the receptacle. Endurance Mechanical: 10,000 cycles. Impact Resistance In accordance with UL746C Terminal Identification Terminals identified in accordance with UL, CSA and International conventions. Product Identification Identification and ratings are a part of the external label and molded into the receptacle mount. Moisture Resistance Outdoor: 4X (Watertight, Washdown) Indoor: Type 12 (Dusttight, Falling Dirt and Non-Corrosive Liquids). Ingress Protection IP67 Suitability Flammability UL94-5VA and V-0 classification. Operating Temperatures Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact. UV Resistance All materials are UV Stabilized. Certifications UL Listed, CSA Certified. Device Description This device provides on/off switched control of a plug connected load and includes an interlocking feature to prevent the plug from being disconnected while the receptacle is energized. The switch cannot be turned "ON" until the plug is inserted properly. UPC Number 78358540600 Weight in LBs 18.95 DATASHEET INFORMATION LINKS: http://www.hubbellcatalog.com/wiring/datasheet.asp?PN=HBL460MIF12W Powered by SixBit's eCommerce Solution

Condition	Used : An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.
Seller Notes	“Excellent condition - no packaging. It has no signs of use other than small scratches on casing from not being boxed but I am listing as used as I am not sure. Includes Instruction Sheet.”
