Hw-515 Dc 2ch Pwm Signal Generator Duty Cycle Pulse Frequency Module Board

US $8.04

New Jersey, United States
Aug 7th

Open on mobile:
QR code

Store Home Promotion Hot Item Add to Fav Contact us Feedback New arrival gigibaobao^-^ Merry Christmas gigibaobao^-^ Merry Christmas Home & Garden Crafts Clothing, Shoes, Accessories Baby Sporting Goods Jewellery & Watches Computers/Tablets & Networking Vehicle Parts & Accessories Health & Beauty Phones & Accessories Pet Supplies Industrial Toys, Hobbies Cameras Electronics Musical Instruments Video Games & Consoles Home Entertainment Home Appliances Business Collectables Dolls, Bears Prodcution Description: HW-515 Micro USB DC 2CH Adjustable PWM Signal Generator Duty Cycle Pulse Frequency Module Board Digital LED Display Tube Descriptions: The frequency is divided into three ranges: XXX (without decimal point): the smallest device is 1 Hz, the range is 1 Hz ~ 999 Hz; XX.X (Decimal point in ten): The minimum block is 0.1 kHz; 0.1 kHz ~ 99.9 kHz XXX (there are Three decimal points): the smallest block is 1 kHz; 1 kHz ~ 150 kHz range Display frequency, for example: "100" means output PWM pulse 100 Hz; "54.1" means that the output of the PWM pulse is 54.1 kHz; "1.2.4". Indicates that the PWM pulse output is 124 kHz Duty cycle in the range: from 0 to 100; The three-frequency duty cycle is the same, all parameters are non-volatile. Parameter settings: The module has three buttons (set), (up), (down); Press (set) to switch the display with four parameters (FR1: PWM1 frequency; dU1: PWM1 duty cycle; FR2: frequency PWM2; dU2: PWM2 duty cycle), before passing the parameters, there will be a corresponding parameter name flash. Press (up), (down) keys to change the current parameter value (long press can quickly add or subtract quickly). Two PWM each has three preset frequencies, frequency display interface, long press (set) key to switch between three types of frequencies, three kinds of frequency cycle is the same value. (XXX: 1 Hz ~ 999 Hz; XX. X: 0.1 kHz ~ 99.9 kHz; XXX: 1 kHz ~ 150 kHz,). Set PWM frequency "S1FXXXT": PWM1 XXX HZ Frequency Setting (001 ~ 999) "S1FXX. XT": Set the frequency of the PWM1 XX. X kHz (00.1 ~ 99.9) "S1F: XXXT": tuning the frequency PWM1 XXX kHz (0.0.1 ~ 1.5.0 ..) 'S1': PWM1 'S2': PWM2 'F': frequencies D: Duty cycle 'T'-final flag Install PWM Duty Cycle "S1DXXXT": Installing PWM1 Duty Cycle XXX; (001 ~ 100) "S2DXXXT": set PWM2 Duty Cycle XXX; (001 ~ 100) Setting a successful return: down; Setup failover: drop. Features: Two independent PWM generators can set the frequency, duty cycle; Wide frequency range, high accuracy; You can order a series of communication. Specifications: Operating voltage: 5-30V, support for micro USB 5.0 in power Frequency range: 1 Hz ~ 150 kHz Frequency accuracy: ± 2% Output current: <30mA Output Amplitude: default 5Vp-p (network) Operating temperature range: -30 ~ + 70 Size: 41*28mm/1.61*1.10" Thickness: 1.6mm/0.06" Serial control Transmission Rate: 9600 BPS Data bit: 8 Stop bits: 1 Parity: no Gas Pressure Regulator: No Scope: 1. As a square wave signal generator that generates a square wave signal; 2. To provide a signal to the stepper motor driver; 3. Adjustable pulse generator for the use of chips; 4. Variable pulse signal, a control circuit (PWM dimming, speed). Notes: 1. There may be slight size deviations due to manual measurement, different measuring methods and tools. 2. The picture may not show the actual color of the item because of different photographing light, angle and display monitor. Included 1 X PWM Signal Generator Pictures PAYMENT DELIVERY WARRANTY Payment must be received within 7 business days of auction closing. If you have bought multiple items from me, you can send me one payment for all the items instead of paying for them individually. When you click the Pay Now button, eBay will automatically determine if there are other items you have won or purchased from me and will combine them for your review. NOTE:Import duties, taxes and chargers are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to bidding buying. DELIVERY 1. We Ship to United States. 2. Items will be shipped within 2 business day on payment received. 3. Item are shipped from United States WARRANTY 12 months Warranty. Buy with confidence! If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact me before you return it. If item is defective in 3 months, We will send you a replacement without extra charger, or offer refund after we receive the defective item. If item is defective after 3 months, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Size	4128mm/1.611.10"
MPN	Does Not Apply
Thickness	1.6mm/0.06"
Operating voltage	5-30V, support for micro USB 5.0 in power
Transmission Rate	9600 BPS
Frequency range	1 Hz ~ 150 kHz
Data bit	8
Frequency accuracy	± 2%
Stop bits	1
Output current	<30mA
Parity	no
Output Amplitude	default 5Vp-p (network)
Gas Pressure Regulator	No
Operating temperature range	-30 ~ + 70
