Hx-pwm Input Dc12v-60v Output 30a Dc Motor Speed Controller Driver

US $39.50

Wuhan, China
Jan 29th

Open on mobile:
QR code

HX-PWM AC12V-65V Input DC0-110V Output 30A 300W DC Motor Speed Controller Driver Specification 1) Working voltage: wide voltage (DC) DC12V-DC60V 2) Control: Default potentiometer control (5K-100K feasible) default 10K, (can be analog 0-5V control, signal line connected to ADJ, ground connection GND, the potentiometer need to be removed in this mode, then it works). (You can control the PWM control signal input, 3-20V level range, 2mA current requirements, PWM signal cable connected to the PWM terminal, ground connection GND, the potentiometer need to be removed in this mode, to make it work). 3) Rated current: 30A, overload and short circuit protection current 35A. (Overcurrent cut output, the red light flashes and buzzer alarm make sound, potentiometer return light is off, overcurrent protection removed.) 4) soft-start function to prevent the motor starting current too big to caused damage to the motor and power supply, (default 1 second soft start), 0-5 seconds adjustable. 5) Enable function, EN pin to GND being connected, stops output at any speed. Disconnection enables returning to work. 6) Control power: 12V250W, 24V500W, 36V750W, 48V1000W, 60V1250W, it is advised that clients give some allowance when selecting the governor when the governor, so that you can extend the life of the governor, the simple selection formula : voltage * current * 0.7 = speed controller limit that can be matched 7) Dimension: 110mm L X 78MM W X 35MM H 8) Pulse width Modulation Range: 0% -100% 9) The governor all use user-friendly terminals, for simpe and flexible wiring. Features PWM power DC motor speed controller: Applicable to DC12-60V low-pressure permanent magnet brush DC motors Package 1x HX-PWM Input DC12V-60V Output 30A DC Motor Speed Controller Driver Payment Method PayPal Preferred Shipping & Delivery We provide free shipping to international via China Post Airmail or Hong Kong Post Airmail, and every parcel will be registered with tracking number. We can also ship by UPS/EMS/DHL/FedEx for alternative shipping method for corresponding fees. International customers may experience delays by customs or national post providers. Review your duty-free limits. Please let us know before payment if you need split shipment. Time of Delivery The time to ship to international via China Post Airmail or Hong Kong Post Airmail quite depends on different destination of the world, it is also subject to change due to the local weather conditions, postal policy and custom checking. Based on the postal Air mail rules and our experience, kindly please be noted that To United States / United Kingdom / Australia, it takes around 10-15 business days; To Canada, it takes around 12-18 business days; To Brazil / South America, it takes around 25-35 business days. To Italy / France / Spain / Germany/ Eastern Europe, it takes around 15-20 business days. Returns & Replacements & Repair We accept returns & replacements within 14 days from the day the customer receive the products, please make first contact within 14 days from receiving the order. Products should be returned in original condition. As a benefit to our customers, we also provide repair within 3 months from the day when this item is shipped out, after repair is done, we will send you the item, but the customer should pay both shipping ways. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
