Hydraforce EP16-S35T Cartridge Logic Element, US $560 – Picture 0
Hydraforce EP16-S35T Cartridge Logic Element, US $560 – Picture 0

Hydraforce Ep16-s35t Cartridge Logic Element

US $560

  • North York, Ontario, Canada
  • Jun 9th
Open on mobile:
QR code
From Manufacturer :DESCRIPTION A spool-type, screw-in, cartridge-style, hydraulic directional element, with multifunction potential when used with other directional, pressure, or flow control devices. OPERATION The EP16-S35 is a spring-biased blocking valve which will shift to allow full flow from 1 to 2 only when pressure at 1 exceeds the cumulative pressure of 3, plus the bias spring pressure value. EP16-S35 is a pilot-to-close directional valve. With no pressure at 3, flow will be allowed from 1 to 2 once the bias spring force is overcome with pressure at 1. It requires a tall cap when specified with bias springs from 6,2 to 16,5 bar (90 to 240 psi). The 240 psi spring reequires an extra tall cap. A manual override option is also available for the valves with bias springs from 6,2 to 16,5 bar (90-240 psi). Note: Orifice discs should not be used with this valve. FEATURES • Multiple function/application potential. • Low pressure drop. • Industry common cavity. • Manual override available with 90, 110, 160, and 240 psi bias springs.  RATINGS Operating Pressure: 240 bar (3500 psi) Proof Pressure: 420 bar (6090 psi) Flow: Up to 189 lpm (50 gpm) Internal Leakage: 164 cc/minute (10 cu. in/minute) max. at 207 bar (3000 psi) Operating Temperature: -40° to 100°C (-40° to 212°F) with Buna seals;    -26° to 204°C (-15° to 400°F) with Fluorocarbon seals;    -54° to 104°C (-65° to 225°F) with Polyurethane seals New , No Box
