Hydraulic Double Pump 40hp 30kw Sperry-vickers Toshiba Sqp31 30gpm 3gpm 2500psi

US $3,750.00

Central Point, Oregon, United States
Jul 20th

Open on mobile:
QR code

Sperry Vickers / Toshiba SQP Double Pump hydraulic pump This motor and pump combination was removed from an injection mold press that was retired for reasons other than hydraulics. The low-volume cartridge was replaced a few years back, which didn't solve the perceived problem, so the old one was apparently not bad after all. This pump has run perfectly for years, and there is no indication of impending failure whatsoever. Nonetheless, it is used, hence, no long term warranty. But if it is found to be immediately defective, let me know, and we can reverse the sale, because I know it works well! max. working pressure: 2500 psi. Output 1: 30 gal/min. Output 2: 3 gal/min. The placard on the pump says, "SQP301... Having studied the available product literature, it appears that this was probably an earlier designation for what is now called SQP31, as the specs and dimensions line up quite well. There may, however, be some differences between the product for sale and the SQP31 data. Motor: Toshiba Electric, 1170 RPM, 30kW (40 HP), 6 pole, 3-phase, 230/460 VAC Frame No. 200L; Cast iron Mounting Holes: Four 18mm bolts on rectangular grid, 318mm (W) by 305mm (L) in inches that is. . . . . . . 12.52 in (W) by 12.01 in (L) Overall Wt: approx. 750 lb Shipping weight to be determined after I have a chance to weigh it. Overall Dimensions: Width: 23 in (including connection can) Height/Dia: 16.5 in Length: 42 in Motor has never been connected to A VFD or motor controller—always connected direct to utility power. I have a series-to-parallel time-delay soft-start circuit (for low voltage use only) available for $175. This circuit will not work if you are installing the pump to run on 460/480 VAC. It works quite well, however, for 230/240 VAC installation. For high voltage connection, soft-start requires a Wye-to-Delta delay switch, which requires a slightly more complex contactor configuration. Copy and paste the following link to see more photos: https://photos.google.com/share/AF1QipMxtHXlB_gzqIOulrKdpzctvMdXc6xSfcQaYdvgIml32rGBtQFVaLb9-cjPOB82Ig?key=ZUF0a1JNaVh1b256VDRINFdoVDNTR3dQUm9VdjFn

“Worked with excellence when removed from service.”

Hydraulic Pump Type

Hydraulic Vane Pump

Flow rate

30 gpm, 3 gpm

Country/Region of Manufacture

Japan

Duty

continuous

Inlet Port Diameter

3.5 inch

Rated Pressure
