Iboard Pro - Arduino Mega2560 With Ethernet Built-in

AU $37.50

Sydney, Australia
Jun 9th

Open on mobile:
QR code

Overview The Iboard Pro is a unique Arduino board which features a WIZnet Ethernet port with POE, an XBee socket, ITDB02 Serial/Parallel LCD module interface, RTC, nRF24L01+ module interface, Micro SD socket and an ATMega2560. This board will add wireless XBee control as well as internet connectivity to your projects. Itâ€™s great for anything from home automation to robot control. The possibilities are endless! DESCRIPTIONThe IBoard Pro is a unique Arduino board which features a WIZnet Ethernet port with POE, an XBee socket, ITDB02 Serial/Parallel LCD module interface, RTC, nRF24L01+ module interface, Micro SD socket and an ATMega2560. This board will add wireless XBee control as well as internet connectivity to your projects. It’s great for anything from home automation to robot control. The possibilities are endless! IBoard Pro can be used as an Ethernet, wireless communication project development platform. IBoard Pro support POE (power on Ethernet) power supply, and Micro SD for mass storage. There are some 3pin electronic brick/ sensor brick interface breakout on board, it offer an easy way for a quick prototyping. You can setup a web server through which you may communicate with a remote Arduino using XBee radios, bluetooth or APC modules. This information can be posted to a web site, or to Twitter. The board requires FTDI basic board to upload sketch, you can use our Foca board to do it. Iboard can be powered by a mini USB , power Jack or POE. Overview IBoard Pro is a unique Arduino board which features a WIZnet Ethernet port with POE, an XBee socket, ITDB02 Serial/Parallel LCD module interface, RTC, nRF24L01+ module interface, Micro SD socket and an ATMega2560. This board will add wireless XBee control as well as internet connectivity to your projects. Itâ€™s great for anything from home automation to robot control. The possibilities are endless! IBoard Pro can be used as an Ethernet, wireless communication project development platform. IBoard Pro support POE (power on Ethernet) power supply, and Micro SD for mass storage. There are some 3pin electronic brick/ sensor brick interface breakout on board, it offer an easy way for a quick prototyping. You can setup a web server through which you may communicate with a remote Arduino using XBee radios, bluetooth or APC modules. This information can be posted to a web site, or to Twitter. The board requires FTDI basic board to upload sketch, you can use our Foca board to do it. Iboard can be powered by a mini USB , power Jack or POE. Spec PCB size 124.46mm x 72.39mm x 1.6mm Power supply 7-23V DC Microprocessor Atmega2560 Indicators PWR, Tx, Rx, COL, FDX, SPD, LINK,TEST Communication Interface Ethernet RJ45,XBee,nRF24L01+,UART,IIC RoHS Yes Electrical Characteristics Specification Min. Typical Value Max. Unit Power Voltage 7 - 23 VDC Input Voltage VH (Target Voltage = 3.3V) 3 3.3 3.6 V Input Voltage VL: -0.3 0 0.5 V Current Consumption - 100 500 mA Hardware Top View Map Pin Map ITDB02 Parallel LCD Module Interface Index of Interface Name of Interface Index of Arduino Pin of Atmega2560 1 GND GND GND 2 DB0 D37 PC0 3 VCC 5V - 4 DB1 D36 PC1 5 NC - - 6 DB2 D35 PC2 7 LCD_RS D38 PD7 8 DB3 D34 PC3 9 LCD_WR D39 PG2 10 DB4 D33 PC4 11 LCD_RD 3V3 3V3 12 DB5 D32 PC5 13 DB8 D22 PA0 14 DB6 D31 PC6 15 DB9 D23 PA1 16 DB7 D30 PC7 17 DB10 D24 PA2 18 Touch_CLK D6 PH3 19 DB11 D25 PA3 20 Touch_CS D5 PE3 21 DB12 D26 PA4 22 Touch_DIN D48 PL1 23 DB13 D27 PA5 24 Touch_BUSY - - 25 DB14 D28 PA6 26 Touch_DOUT D3 PE5 27 DB15 D29 PA7 28 Touch_IRQ D2 PE4 29 LCD_CS D40 PG1 30 SD_MISO D50 PB3 31 NC - - 32 SD_SCK D52 PB1 33 LCD_RST D41 PG0 34 SD_MOSI D51 PB2 35 NC - - 36 SD_CS D53 PB0 37 LED+ 3V3 3V3 38 NC - - 39 LED- GND GND 40 NC - - ITDB02 Serial LCD Module Interface Index of Interface Name of Interface Index of Arduino Pin of Atmega2560 1 5V 5V - 2 GND GND - 3 RESET D37 PC0 4 RS D36 PC1 5 SDA D35 PC2 6 SCL D34 PC3 7 CS D33 PD4 8 NC - - ITDB02 EB Interface Index of Interface Name of Interface Index of Arduino Pin of Atmega2560 1 EB0 A0 PF0 2 EB1 A1 PF1 3 EB2 A2 PF2 4 EB3 A3 PF3 5 EB4 A4 PF4 6 EB5 A5 PF5 7 EB6 A6 PF6 8 EB7 A7 PF7 9 EB8 A8 PK0 10 EB9 A9 PK1 11 EB10 A10 PK2 12 EB11 A11 PK3 13 EB12 A12 PK4 14 EB13 A13 PK5 15 EB14 A14 PK6 16 EB15 A15 PK7 nRF24L01+ Module Interface Index of Interface Name of Interface Index of Arduino Pin of Atmega2560 1 GND - - 2 3V3 - - 3 CE D12 PB6 4 CS D11 PB5 5 SCK D9 PH6 6 MOSI D8 PH5 7 MISO D7 PH4 8 IRQ - PE7 Micro SD Socket Index of Interface Name of Interface Index of Arduino Pin of Atmega2560 2 SD_CS D4 PG5 3 SD_MOSI D51 PB2 4 3V3 - - 5 SD_SCK D52 PB1 6 GND - - 7 SD_MISO D50 PB3 W5100 Communication Interface Index of Interface Name of Interface Index of Arduino Pin of Atmega2560 1 W5100_CS D10 PB4 2 SD_MOSI D51 PB2 3 SD_SCK D52 PB1 4 SD_MISO D50 PB3 5 W5100_RESET D47 PL2 Specification Microcontroller ATMega2560 Max Frequency 16MHz RAM Capacity 8K FLASH Capacity 256K External Resources Onboard SD socket Onboard Ethernet Display Electronic Brick Interface Power Supply External 12V External 24V External 7V External 9V I/O Operation Level 3.3V Board Size 124.46mm x 72.39mm Model IM120724002 Version 1.0 Weight 80.00g Accessories No Download Datasheet DS_IM120724002_IBoardPro Schematic SCH_IM120724002_IBoardPro Demo Code DC_IM120724002_IBoardPro Fritzing Parts Fri_IM120724002_IBoardPro

Condition:	New	Brand	IteadStudio
Model	IM120724002
