Icl8038 Function Signal Generator Module Ic Diy Sine Square Triangle Wave Dds

US $0.99

Shenzhen ,Guangdong, China
Aug 11th

Open on mobile:
QR code

Store CategoriesStore Categories eBay Motor Fashion Books, Movies & Music Electronics Collectibles & Art Home & Garden Sporting Goods Toys & Hobbies Business & Industrial Health & Beauty Other Item Description 1PCS ICL8038 IC: 1XICL8038 ICL8038CCPD INTERSIL IC OSCILL GEN/VOLT CONTROL 14DIP NEW ICL8038 Kits: Notice: Requires a certain DIY ability, you need to weld the kit yourself ICL8038 pin functions: 1 foot, 12 foot: sine waveform adjusting terminal; 2 foot: sine wave output; 3 foot: triangle wave output; 4 foot, 5 foot: the frequency and duty cycle (or waveform asymmetry) adjustment; 6 foot: V +, the positive power supply; 7 foot: offset; 8 foot: frequency adjustment input terminal; 9 foot: square wave output. This is an open collector output terminal, work should take a load resistor to the corresponding positive power supply terminal from the pin, to get a TTL-compatible square-wave output, the load resistance must be connected to + 5V power supply; 10 foot: timing capacitor terminal; 11 foot: V-, negative power supply terminal or the ground. Use positive and negative power supply, 11 feet to the negative supply, the output waveform are symmetrical with respect to 0V; use a single positive power supply, 11 feet grounded, the output waveform is unipolar, uniform voltage is + VCC / 2; 13 feet, 14 Feet: Empty foot. The kits are designed for a frequency range is 50-5KHz, two bands with a switch S to switch, RP1 is the frequency adjustment, RP2 is the duty cycle adjustment, RP3 is a sine wave distortion adjustment. Circuit uses 12V single power supply, input from the X1; X2, X3 is a waveform output side, you can use oscilloscope to observe three output waveforms. Model: ICL8038 Input: 12V DC Frequency range 50-5KHz, Size:6cm*4.5cm*0.2cm Package Included: 1 set function signal generator module and electronic kit ICL8038 Welded(Yellow): (1) output triangular wave, square wave and sine wave. (2) frequency range: 10HZ ~ 300kHz (3) Duty range: 2% to 98% (4) Low-distortion sine wave: 1% (5) low temperature drift: 50ppm / (6) of the triangular wave output linearity: 0.1% (7) Power supply: + 12V ~ + 24V Package included: 1 x DC 12V-24V ICL8038 DDS Signal Generator Module Sine Square Triangle Wave ICL8038 Blue: Features: Working voltage: 12V ~ 15V Output: Triangular wave, Square wave and sine wave. Frequency range: 10HZ ~ 450kHz Low distortion sine wave: 1% Duty cycle range: 2% to 98% Low temperature drift: 50ppm / Triangular wave output linearity: 0.1% Working temperature: 0 ~ 70 Board size: 54.5*37.8mm Functions: VCC,GND: working voltage AC: with DC bias output G: ground DC: pure signal output R11: Frequency adjustment R12: Square wave duty cycle adjustment R13: Sine wave linear adjustment R14: Amplitude adjustment R15: Square wave linear adjustment Jumper P2: select different waveforms(triangular, square or sine waves) Jumper P3: select different frequency ranges 10Hz-450Hz 90Hz-1.5KHz 940Hz-15KHz 6KHz-120KHz 20KHz-450KHz Package Include: 1 x ICL8038 Low/Medium Frequency Signal Source Waveform Signal Generator Sine Wave ICL8038 Low-frequency: 1. Module size:50x50mm 2. Module working voltage:±5V-±12V DC 3. Low Frequency Drift with Temperature : 50ppm/oC 4. Low Distortion Sine Wave:011% 5. Triangle Wave Output Linearity : 011% 6. Wide Frequency Range : 01001Hz to 300kHz 7. Duty Ratio Range : 2% to 98% 8. Simultaneous outputs an arbitrary Sine, Square, and Triangle Wave Package included: 1 x Low-frequency Signal Source Generator Module Feedback Payment Shipment About us Feedback We appreciate positive feedback . we always try our best to service our customers . so if you have antquestion ,PLEASE DON’T HESITATE TO TELL US, we are always here to offer help . Payment We prefer PayPal .For purchasing multiple items , please contact us for a combined invoice . generally we would like to receive payment thin 48 hours if . Shipment We provide airmail service with good package . The items will be shipped within the nest 2 business days after we received the payment . when you buy multiple items ,your shipping cost will be combined with discount . SHIPPING TIME (weekends/holidays excluded) Country Name Shipping Time Country Name Shipping Time USA/Canada 10 -15d Spanish/Portugue 10-25d East/South Asia 10 -15d France/West Asia 10-25d United Kingdom 10 -20d Italy 10-30d Australia/New Zealand 10 -15d West Asia/Middle East 15-25d Most Country of West/North Europe 10-20d South America and Africa 15-30d East /Middle Europe/Russia 10-25d About us NEW, GOOD QUALITY, ORIGINAL PACKAGE LARGE STORE AND THE LOWEST PRICE NO-QUESTION-REFUND, FOR LARGE QUANTITY ,OFFER BETTER PRICE,ORIGINAL PACKING(TAPE REEL/TUBE/TRAY We specialize in electronic components . ICs, Capacitors, Diodes, Resistors, LEDs, Transistors, and so on. Especially in Hard To Find Parts . we only sell NEW , ORIGINAL parts . please buy with confidence .We offer NO-QUESTION-REFUND go to my store

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
EAN	Nicht zutreffend
MPN	Does not apply
Type	Module/IC/DIY
Model	ICL8038
Marke	Markenlos
UPC	Does not apply
Herstellernummer	Nicht zutreffend
