Icm Controls Icm292 Rheem 62-24140-04

US $115.20

Los Angeles, California, United States
Jul 19th

Open on mobile:
QR code

ICM Controls ICM292 RHEEM 62-24140-04 Description Control voltage: 24 VAC (18-30 VAC), 60 Hz Line voltage: 115 VAC, 60 Hz Power consumption: 0. 3A plus gas valve current at 24 VAC Operating temperature: -40°C (-40°F) to 75°C (176°F) Post-purge: 90, 120, 160 and 180 seconds ICM292 Gas Ignition Control Board Low cost, direct replacement ignition control Features: Direct Spark Ignition (DSI) control board Microprocessor-based Controls inducer motors, air cleaner (if equipped), humidifier (if equipped), spark ignitor and the gas valve Monitors timing, trial for ignition, system switches, flame sensing and lockout 100% lockout safety feature Compatible with LP or Natural Gas LED indication for status and fault codes to aid in troubleshooting Specifications: Control voltage: 24 VAC (18-30 VAC), 60 Hz Line voltage: 115 VAC, 60 Hz Power consumption: 0.3A plus gas valve current at 24 VAC Operating temperature: -40°C (-40°F) to 75°C (176°F) Timing-Pre-purge: 30 seconds-Trial for ignition: 7 seconds- Retries: Two groups of two, 30 seconds delay within the group and 3minutes delay between groups-Lockout: 1 hour- Post-purge: 90, 120, 160 and 180 seconds Inputs- Power: 24 VAC and COM-Thermostat interface: R, W, Y and G- System switches: Vent Pressure and Limit switches (Main and Over-temperature switches in series)- Flame Sensing- Heat blower OFF delay miniature slide switch set Outputs- Spark- Gas Valve: GV- Inducer draft motor: IDM- Blower motor: FAN, COOL and HEAT speeds- Electric Air Cleaner: EAC- Humidifier relay: HUM- Heat/Cool relay: H/C LED indicators- Power, green LED: PWR- Status, green LED: OK- Flame status, yellow LED: FLAME Used in Honeywell, Rheem, Ruud Heat Controller, Weatherking FurnaceModels and many more that are not listed here:GLH-06EAUEA, GLH-07EAMGA, GLH-07EAUEA, GLH-10EAMEA, GRA-07EYBG278 andGTA-07EYBG278.Replacement for Obsolete Circuit Board Part Numbers:62-24140-0 SHIPPING This item ships worldwide! Add to cart or click "Buy It Now" to see international shipping prices. The international shipping price includes all import fees with NO SURPRISE CHARGES and no additional fees upon delivery. We offer FREE shipping on all domestic orders! We use a selection of shipping services such as UPS, FedEx, USPS etc. US buyers: we only ship to the lower 48 states, no APO/FPO addresses or PO Boxes allowed. Local pickups and combined shipping options are not provided at this time. International customers: please be aware that all of our items, unless otherwise stated, will only run on 120 volts. Please check to make sure your country complies with these specifications. RETURNS You can return a product for up to 30 days from the date you purchased it. Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt. FEEDBACK Customer satisfaction is important to us. If you have any problem with your order, please contact us and we will do our best to make you satisfied. Thank you for shoping with us at shippingentertainment PAYMENT We accept payment by any of the following methods: credit, debit, and gift cards; Apple Pay; Google Pay; PayPal and PayPal CreditPlease pay as soon as possible after winning an auction, as that will allow us to post your item to you sooner!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	62-24140-04
Item Thickness	5 in
Country/Region of Manufacture	United States
MPN	RTG20146
Custom Bundle	No
Item Length	4 in
Item Width	4 in
Color	Multicolor
Compatible Brand	For ICM Controls, For Rheem, For Carrier
Item Weight	11.2 oz
Material	Stainless Steel
Brand	ICM Controls
Power Source	Gas
Manufacturer Warranty	Other: See Item Description
Type	Ignition Control Board
Amperage	0.3A
Compatible Model	LP or Natural Gas LED
Plug Profile	Panel Mount
Compatible Product	Central Air Conditioner, LP or Natural Gas LED
Voltage	24 V
UPC	800442013329
