Ideal Networks R158003 Vdv Ii Pro Mm Cable Tester W/ops & Accessories

US $2000

Melrose, Massachusetts, United States
Jun 22nd

Open on mobile:
QR code

Subscribe to Our Newsletter IDEAL Networks R158003 VDV II Pro MM Cable Tester w/Added Options & Accessories Brand: IDEAL Networks Model Number: R158003 Ref No: R158003 Condition: NEW UPC: 783250764860 Data Sheet Product Overview Features Performs standard tests for copper cabling, including: Coax, 6 pin (RJ11/12), 8 Pin RJ45), Connectors of Copper Cables Testing; Wiremap for Miswires, Splits Pairs, Shorts, Opens, and Crossovers A/B Cables; Analog Tone Generator; Voltage Protection; Shield Multimedia Support: RJ45, RJ11/RJ 12 and coax ports for wiremap verification of low voltage copper cables TDR Length and testing and troubleshooting: Pinpoints cable faults eliminating unnecessary guess work Tone Generator: Ability to identify and trace cables with a compatible inductive tone probe (Optional) PoE Detection: PoE service detection with pin and voltage information Cat 5, Cat 5e, Cat 6, Cat 6A, Cat 7, UTP and STP testing: Support for all common LAN cables (TIA 568A/B wiring schemes) Large 2.9" Backlit Screen: Instantaneous, easy to read test results Phone Service Detection: Identifies analog (PBX_ and digital (ISDN) telephone services Ethernet Detection: Displays network rate and duplex information Voltage Protection: Cable testing disabled if >2V of non-standard voltage is detected Description The IDEAL Networks R158003 VDV II Pro Voice, Data and Video Cable Verifier is an easy to use cable tester that checks the integrity of copper cables commonly found in domestic, commercial or industrial voice, data or video installations, including telephone wiring, data network, and video/security cabling.|Employing state-of-the-art technology, the IDEAL Networks R158003 VDV II Pro offers functionality not previously available in a wire mapper. The advanced wire map engine accurately displayed complex wiring fault instantaneously while the integrated TDR (Time Domain Reflectometry) simplifies troubleshooting and improves on-site productivity. The key feature of the VDV II is to check the wiring of all three copper types is terminated correctly into its relevant connection.|Accuracy|The flagship IDEAL Networks R158003 VDV II Pro utilizes a TDR to accurately measure cable length and provide distance to fault information. TDR's work by interjecting a signal into the cable and measuring the time for any signal to be reflected back after encountering changes in impedance caused by cable damage, open and short circuits. The recorded time is then translated into an accurate distance measuremtn. TDR really helps pinpoint where cabling faults occur. This speeds up fault finding as well as minimising disruption and potential damage to fixtures and fixings.|Speed|With Comprehensive details on faults such as opens, shorts, reverses, miswires and split pairs, the IDEAL Networks R158003 VDV II Pro identifies wiring errors instantly. The integrated RJ11/RJ12 (voice), RJ45 (data), and F-Type (video) connectors allow faster testing f most types of low voltage cables by eliminating the need for separate testers or adapters.|Intelligence|Connection Issues are not always associated with cable faults, so the IDEAL Networks VDV II Pro has the capability to help identify service related issues. By detecting the presence of voltage and checking polariy, the IDEAL Networks R158003 VDV II Pro quickly determines which type of media service is running over the cable, such as ISDN, PBX, and PoE (power over Ethernet) resulting in faster fault diagnosis. Troubleshooting active Thernet networks is also made easier with in-built network detection that displays network rate and duplex information. Furthermore, to prevent potentially costly damage to the tester, all VDV II's are smart enough to know whe they have been plugged into an outlet where non-standard voltage is present. Terms & Conditions Please note estimated delivery time above. Contact us for details or if you have a delivery requirement. We ask for your patience while striving to ensure your shipment arrives quickly and accurately. Domestic Shipping FREE Standard Shipping on items OVER $75 to continental U.S. Add $24 for AK, HI, or PR. PO Boxes/APOs require USPS shipping and may therefore experience longer lead times 6.25% Sales Tax for shipping to MA International Shipping Due to international voltage requirements, please ask us prior to purchasing to confirm your product will operate correctly in your country. Please contact us for shipping rates to any overseas U.S. territories. International customers are responsible for all shipping charges, including any duties or taxes.
