Idirect Infiniti Satellite Router/modem Model Number 7350

US $8300

Beloeil, Belgium
Jan 29th

Open on mobile:
QR code

iDirect INFINITI SATELLITE ROUTER/MODEM Model Number 7350 tested 100 % ok YOU ARE PURCHASING THE FOLLOWING Manufacture: iDirect Model: 7350 Satellite Router Condition: USED System Specifications Table 2 and Table 3 summarize the electrical specifications of the 10 to 40W 1:1 Uplink Downlink Redundant System Table 2 – System RF Specifications Parameter Specification Up-Link Input IF Frequency 950 to 1525 MHz LO Frequency 4.9 GHz Output RF Frequency 5.9 to 6.425 GHz Output Power @ P1dB Compression point 46 dBm (40W) min Output Power Saturation point 47 dBm (50W) typical Conversion Gain 65 dB, nom Gain Flatness (small signal) ±2.5 dB, nom over full band at 250C Phase Noise -60 dBc/Hz, max@ 300 Hz off the carrier; -70 dBc/Hz, max@ 1 kHz off the carrier; -80 dBc/Hz, max @ 10 kHz off the carrier; -90 dBc/Hz, max @ 100 kHz off the carrier; -100 dBc/Hz, max @ 1 MHz off the carrier Spurious -50 dBc max, @Pout = P1dB rated IM-3 -26 dBc max@ Pout = 43dBm SCL (Two equal signals total, 5 MHz separate) Harmonics -50 dBc @ P1dB nom Output RL (cold) -18 dB, min, with built-in output isolator Source VSWR 1.5 :1, max (operational) Load VSWR 1.5 :1, max (operational) Infinite at any angle with no damage module with built-in output isolator Power Consumption per BUC: RF Booster BUC 110 / 220VAC; 250 W, max 24VDC 1A max via IF cable; supplied by IDU Down-Link Input RF Frequency 3.625-4.2 GHz LO Frequency 5.76 GHz Output IF Frequency 950 to 1525 MHz Noise Temperature 45 K max Conversion Gain 65 dB nom Phase Noise -63 dBc/Hz, max@ 100 Hz off the carrier; -73 dBc/Hz, max@ 1 kHz off the carrier; -83 dBc/Hz, max @ 10 kHz off the carrier; -90 dBc/Hz, max @ 100 kHz off the carrier; Power Consumption per LNB 24VDC 0.35A max. mitec 10 to 40W 1:1 Uplink Downlink Redundant System Introduction Rev 1 Page 3 Table 3 – System Electrical Specifications Parameter Specification Up-Link IF Input Port Impedance 50 Ohm IF Input port DC Block; 10MHz Block 10MHz Reference Source 0±5dBm; 10-8 stability; injected into each IF line DC Supply 24VDC 2A max; injected into IF line Down-Link IF Output Port Impedance 75 Ohm IF Output Port DC Block; 10MHz Block DC Supply 24VDC 0.5A max; injected into IF line Power Supply AC Input Two 110/220 VAC Auto ranging; 160W max each DC Output 1 Two 24VDC 4 A min DC_OUT1 Efficiency 85% nom DC Output 2 Two 12VDC 2.5 A min DC_OUT1 Efficiency 80% nom
