Ifm Efector Sm6001 Flow Meter Sensor

US $229.00

Palos Heights, Illinois, United States
Jul 10th

Open on mobile:
QR code

IFM EFECTOR SM6001 Flow Meter New without box (with port and connection covers) Product characteristics Number of inputs and outputs Number of digital outputs: 2; Number of analog outputs: 1 Measuring range 1.5...396 gph 0.03...6.6 gpm Process connection threaded connection G 1/2 DN15 flat seal Application System gold-plated contacts Application Totalizer function; for industrial applications Installation connection to pipe by means of an adapter Media Conductive liquids; water; water-based media Note on media conductivity: 20 µS/cm viscosity: < 70 mm/s (40 °C) Medium temperature [°F] 14...158 Pressure rating [bar] 16 Pressure rating [psi] 232 MAWP (for applications according to CRN) [bar] 17.7 Electrical data Operating voltage [V] 18...30 DC; (according to EN 50178 SELV/PELV) Current consumption [mA] 95; (24 V) Min. insulation resistance [M] 100; (500 V DC) Protection class III Reverse polarity protection yes Power-on delay time [s] 5 Inputs / outputs Number of inputs and outputs Number of digital outputs: 2; Number of analog outputs: 1 Inputs Inputs counter reset Outputs Total number of outputs 2 Output signal switching signal; analog signal; pulse signal; IO-Link; (configurable) Electrical design PNP/NPN Number of digital outputs 2 Output function normally open / closed; (configurable) Max. voltage drop switching output DC [V] 2 Permanent current rating of switching output DC [mA] 200 Number of analog outputs 1 Analog current output [mA] 4...20; (scalable) Max. load [] 500 Analog voltage output [V] 0...10; (scalable) Min. load resistance [] 2000 Pulse output flow rate meter Short-circuit protection yes Type of short-circuit protection yes (non-latching) Overload protection yes Measuring/setting range Measuring range

“Brand new without box.”

Flow Meter Type

Electromagnetic Flow Meter

Brand

Efector

MPN

SM6001
