Ifr A-7550 Spectrum Analyzer

US $1800

Scarborough, Ontario, Canada
Jun 16th

Open on mobile:
QR code

IFR A-7550 SPECTRUM ANALYZER The IFR Systems (Aeroflex) A-7550 spectrum analyzer is a wide band, very sensitive receiver. It works on the principle of "super-heterodyne receiver" to convert higher frequencies (normally ranging up to several 10s of GHz) to measurable quantities. The received frequency spectrum is slowly swept through a range of pre-selected frequencies, converting the selected frequency to a measurable DC level (usually logarithmic scale), and displaying the same on the CRT of the IFR Systems (Aeroflex) A-7550. The CRT displays received signal strength (y-axis) against frequency ( x-axis). Some applications for IFR Systems (Aeroflex) A-7550 Spectrum Analyzers include Site Monitoring: Verify that the frequency and signal strength of your transmitter is accurate. Interference: Before a system is installed you use a IFR Systems (Aeroflex) A-7550 spectrum analyzer to verify that the frequencies (you plan to use) are not occupied or if the presence of a very strong signal will interfere with your new setup. Interference can be created by a number of different situations. Other tests that utilize the IFR Systems (Aeroflex) A-7550 spectrum analyzer features include antenna isolation, co-channel interference, adjacent channel power, occupied bandwidth, intermodulation, microwave or satellite antenna alignment, and characterization of components. Feature: Minimum Frequency: 10kHz Maximum Frequency: 1GHz Resolution bandwidth: 300Hz Performance Characteristics of the A-7550 Form Factor Mainframe Input Impedance 50 MOhm Minimum Frequency 10 kHz Maximum Frequency 1 GHz Frequency Accuracy 0.0025 % Zero Span Yes Minimum Span 1 kHz Maximum Span 100 MHz Minimum Sweep Time 5 ms Maximum Sweep Time 2 s Minimum Resolution Bandwidth 300 Hz Maximum Resolution Bandwidth 3 MHz Resolution Bandwidth Steps 1/10/100 Minimum Single-Side-Band Noise 65 dBc/Hz Maximum Safe AC Input 30 dBm Maximum DC Input 4 V Maximum Dynamic Range 70 dB Probe Power No Noise Source Driver No Front Panel 1) Display Screen ( Green Phosphor, 380 horizontal x 480 vertical ) 2) Analyzer Input ( Bnc connector ) 3) Cal Out ( Bnc connector ) 4) Tracking Adjustment ( Recessed screw driver adjustment ) 5) Generate Output ( Bnc connector ) 6) Ext Amp ( DC jack) 7) Power Led ( Red ) 8) Power Switch ( 3 position, Power/Off/Battery ) 9) Trace Adjust ( Control knob ) 10) Graticule Adjust ( Recessed screw driver adjustment ) 11) Volume ( Control knob ) 12) Annunciator ( Recessed screw driver adjustment ) 13) Squelch ( Control knob ) Front Panel Keyboard 14) RF Attn ( Buttons - increase / decrease ) 15) IF Gain ( Buttons - increase / decrease ) 16) Scan Width ( Buttons - increase / decrease ) 17) Sweep Rate ( Buttons - increase / decrease ) 18) Numeric Keypad ( Buttons - 0 - 9, decimal, enter ) 19) Res / Bandwidth ( Button - reset auto B/w selection ) 20) 2dB/10dB/Lin ( Button - vertical graticule scale selection ) 21) RF / Enter ( Button - RF Center frequuency ) 22) Menu ( Button - menu select ) Rear Panel 1) DC Fuse ( 7.5 Ampere, 32 VDC ) 2) DC Power Input Connector ( 12 - 30 VDC Nominal ) 3) AC Power Input Connector ( 106 - 266 VAC, 50 - 400 Hz. ) 4) AC Line Fuse ( 2.5 Ampere, 250 Volt ) 5) Analog Video Out Connector ( Bnc, !.0 Megohm impedance, 800 mVDC Output ) 6) Sweep Output Connector ( Bnc, 1.0 Megohm impedance, 0 - 5 VDC output ) 7) Fan Exhaust Port ( Do not block or restrict ) 8) RS-232C Connector ( DB 25 female ) 9) Vertical Standoffs and feet ( For floor useage ) 10) Horizontal feet ( For bench - shelf useage ) 11) Carrying Handle ( For carrying and horizontal tilt adjustment ) Optional Features 1) Battery No 2) Tracking Generator Yes 3) External Amplifier No 4) 10.7 Mhz FM/AM receiever Yes 5) GPIB No 6) RS 232C Yes 7) 50/75 ohm selectable impedance Yes 8) Quasi Peak Filter No 9) Maintenance Kit No 10) Camera Mount Adapter No 11) Carrying Case No The unit is in good working order, passes self test mode, and is great condition. Comes with Operational Manual and Maintenance Manual CD Item will be mailed within 5 business days upon receipt of all funds .FOR OVERSEAS RATES EMAIL ME ,This mailing rate is for NORTH America ONLY FLAT RATE..ALL BUYERS be aware of postal delays ....we combine shipping when possible, all sales are final AS IS, NO PICK UPS.
