Ilc Lighting Control - Emergency Lighting Transfer Switch

US $400.00

Los Angeles, California, United States
May 26th

Open on mobile:
QR code

ILC Lighting Control - Emergency Lighting Transfer switch. Condition is "New". Shipped with USPS Priority Mail. Branch Circuit Emergency Lighting Transfer Switch for 2,3 and 4-wire Dimmable Loads. The Model EPC-D-F-ATS is a single zone, silent emergency transfer control with universal dimming capability. It can be used with 2 and 3-wire line voltage dimming systems, as well as 0-10V. Dali and Lutron EcoSystem. The EPC-D-F-ATS allows emergency lighting to be dimmed with normal lighting during normal times. In the event of a utility power interuption, the EPC-D-F-ATS will automatically transfer designated emergency fixtures from the dimming control to the emergency power source and bring them to full brightness, regardless of whether the dimming system is in operation or turned off. SPECS Model No. EPC-D-F-ATS Sensing Input 120v-277v Load Rating 120v-277v (16A) Ballast Load Rating 16A Magnetic/16A Electronic Incandescent Load 1920W (120v) / 4432W (277v) Warranty 5 Year Replacement Warranty Mounting 4-11/16" Junction Box Rating UL94V-0 Shipping Weight/Color 18oz./White Temperature 32 degrees-140 degrees F Flush Mounted Size 6" X 6" X .5" Body Size 4" X 4" X 2.3" Features: Slim, attractive universal mount enclosure allows flush, surface, panel, and box mounting. Utility & Emergency Power Indicator LED’s Integral front mounted test switch Voltage Surge Protection Includes field-selectable Automatic Testing & Fire Alarm Interface options Triple Interlock (electrical, mechanical, and time delay) maximizes safety and reliability of EPC-D-F-ATS, by eliminating arcing and the potential for phase to phase shorts between separate power sources during transfer. Oversized 50A rated relay contacts allow high inrush loads to be used safely and reliably. Tested at over 5000 cycles Works with both inverter and generator systems, normally-on and normally-off type.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	ILC
MPN	EPC-D-F-ATS
Custom Bundle	No
Country/Region of Manufacture	China
Model	EPC-D-F-ATS
Modified Item	No
