Imc Boxer Fan Tubeaxial Model Bc2206f-7-10 7000 Rpm 115v 400 Hz 4140-00-525-9214

US $24.50

Farmingdale, New York, United States
Jan 29th

Open on mobile:
QR code

IMC MAGNETICS BOXER FAN TUBEAXIAL MODEL BC2206F-7-10 7000 RPM 115V 400 HZ NSN 4140-00-525-9214 CONDITION; AS REMOVED BUT IN NOS CONDITION. 14 DAY WARRANTY FOR COMPLETE REFUND ALT P/NS: CURTISS-WRIGHT CONTROLS BC2206F-7-10, BC2206F7-1-1 HONEYWELL INTL 2129521-5 US GOVT PRICE 2011 $763.00/EA DLA PROCURED ITEM FOR 2014 Name Value SPEED ADJUSTMENTS SINGLE SPEED LENGTH 1.500 INCHES NOMINAL FLOW DIRECTION OUTWARD ENVIRONMENTAL PROTECTION EXPLOSION PROOF AND FUNGUS RESISTANT AND HUMIDITY PROOF AND SHOCK PROOF AND VIBRATION PROOF AMBIENT TEMP AT FULL RATED POWER -25.0 DEG CELSIUS AND 175.0 DEG CELSIUS OPERATING SPEED AT RATED CAPACITY IN RPM 6800.0 ELECTRICAL CONNECTION TYPE TERMINAL BLOCK STATIC PRESSURE AT SPECIFIED AIR FLOW RATE 0.0 INCHES OF WATER DRIVE TYPE DIRECT PRIME MOVER TYPE ELECTRIC MOTOR INCLOSURE TYPE FULLY INCLOSED MOUNTING FACILITY TYPE AND QUANTITY 2 FLANGE AND 8 UNTHREADED HOLE ROTATION DIRECTION FOR WHICH DESIGNED COUNTERCLOCKWISE AIR FLOW RATE 265.000 CUBIC FEET PER MINUTE MAXIMUM VOLTAGE IN VOLTS AND CURRENT TYPE 115.0 AC PRIME MOVER POWER RATING 0.080 HORSEPOWER HOUSING INSIDE DIAMETER 4.450 INCHES NOMINAL PRIME MOVER DRIVE SHAFT BEARING TYPE BALL PHASE SINGLE SPECIAL FEATURES 4.690 IN. SQ FLANGE BOTH ENDS VENTURI TUBE FREQUENCY IN HERTZ 400.0 MATERIAL PLASTIC POLYCARBONATE BLADE SURFACE TREATMENT ENAMEL HOUSING STYLE DESIGNATOR FIXED TEST DATA DOCUMENT 19315-2129521-5 DRAWING (THIS IS THE BASIC GOVERNING DRAWING, SUCH AS A CONTRACTOR DRAWING, ORIGINAL EQUIPMENT MANUFACTURER DRAWING, ETC.; EXCLUDES ANY SPECIFICATION, STANDARD OR OTHER DOCUMENT THAT MAY BE REFERENCED IN A BASIC GOVERNING DRAWING) SURFACE TREATMENT ANY ACCEPTABLE

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second, or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	IMC MAGNETICS" BOXER"
MPN	4140-00-525-9214
Model	BC2206F-7-10
Country/Region of Manufacture	United States
