IMS-1(30A Single-channel H-Bridge Motor Driver Module, Arduino,Intelligent Car), US $17.99 – Picture 0
IMS-1(30A Single-channel H-Bridge Motor Driver Module, Arduino,Intelligent Car), US $17.99 – Picture 1
IMS-1(30A Single-channel H-Bridge Motor Driver Module, Arduino,Intelligent Car), US $17.99 – Picture 2
IMS-1(30A Single-channel H-Bridge Motor Driver Module, Arduino,Intelligent Car), US $17.99 – Picture 0
IMS-1(30A Single-channel H-Bridge Motor Driver Module, Arduino,Intelligent Car), US $17.99 – Picture 1
IMS-1(30A Single-channel H-Bridge Motor Driver Module, Arduino,Intelligent Car), US $17.99 – Picture 2

Ims-1(30a Single-channel H-bridge Motor Driver Module, Arduino,intelligent Car)

US $17.99

  • ???, ??, China
  • Jan 29th
Open on mobile:
QR code
30A Single H Bridge Motor Driver Module PID for Arduino Intelligent Car Description: 30A Single H Bridge Motor Driver Module PID for Arduino Intelligent Car Descriptions: - Designed for Arduino intelligent car, the whole bridge DC brush motor drive,for hollow cup motor is very good,PID program source send by email. - This drive brake quickly, and  easy to operation. The customers evaluation that its better than the MC33886 etc. - The driver use the whole bridge drive chip + extremely low impedance MOSFET.make the MOSFET switching losses to lowest. Improve power utilization rate. - MOSFET drive chip with hardware brake function and power feedback function. - The current shock resistance MOSFET type, resistance is 0.005 ohm, can quickly make MOSFET open channel, improve the speed of the motor curvature, also canrapid in electrical braking. This can make of car can quickly start also can quickly kill car. - Drive can work at 0%-98% of the PWM duty cycle, because the drive is NMOS circuit,NMOS circuit features is not to 100% PWM, when PWM 100% of control circuit,long time carries out the operation can lead to drive damage Performance parameters: - Rated voltage: 3 V-15 V - R1 short circuit, VCC and B + short circuit. VCC output voltage and drive the input voltage. - R1 open circuit, VCC and B + disconnect.   VCC input voltage 3-12 V. - Rated current: 30 A - Current peak: 70 A - Switching frequency: 1 K to 200 kHz - Dimensions: 5.0 cm (long) * 5.0 cm (wide) * 3.1 cm (high) Pin Defination: - V +                Power Input + - GND             Power Input - - EN                 Driver Enable, high enable, low off - RPWM          Forward PWM input, high active - LPWM          Reverse PWM input, active high - CT                 Current signal output,analog signal - VT                 Voltage signal output, analog signal Package include: - 1x Driver module   Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warrenty It is not my Duty for Custom Tax All item(s) will be shipped via int'l register air mail or EMS, the time normally takes 7-15 business days. may be later arrivel if the item be check by custom; We only accept paypal payment. eBay Cross Border Trade powered by Channel Effect
